Wilwood High-Volume Master Cylinders 260-6765
Wilwood High-Volume Master Cylinders 260-6765
52 in stock
Couldn't load pickup availability
/update?link=products%2Fwil-260-6765_yp_xl.jpg){kind=link}
Product Description
Wilwood High-Volume Aluminum Master feature high pressure die-cast bodies from high-grade aluminum. Wilwood. High-Volume Master Cylinders have the highest fluid capacity of any integral reservoir design. With a total capacity of 8.2 ounces, there is at least 26% more fluid volume than other brands. . With 1-7/16" of piston travel, it offers extra margin when used with large piston calipers. Heavy duty internal springs provide fast retraction. Formed steel lids with bellows type gaskets keep the moisture out. Wilwood master cylinders use common dimensions for flange or side mounting and a 1/8-27 NPT outlet port.
Wilwood high-volume master cylinders are the perfect solution for your braking needs. These master cylinders feature high-pressure die-cast bodies with an 8.2oz integral reservoir. Available in several bore sizes and utilize a 1.430 in. piston stroke.
Application Summary
Part Type
description
| market_ |
Wilwood High-Volume Aluminum Master feature high pressure die-cast bodies from high-grade aluminum. Wilwood. High-Volume Master Cylinders have the highest fluid capacity of any integral reservoir design. With a total capacity of 8.2 ounces, there is at least 26% more fluid volume than other brands. . With 1-7/16" of piston travel, it offers extra margin when used with large piston calipers. Heavy duty internal springs provide fast retraction. Formed steel lids with bellows type gaskets keep the moisture out. Wilwood master cylinders use common dimensions for flange or side mounting and a 1/8-27 NPT outlet port. |
|---|---|
| product_ |
M/C,HIGH VOLUME,.875 |
| product_ |
MASTER CYLINDER |
s_item
| department | Brake Systems |
|---|---|
| section | Master Cylinders & Boosters |
| name | Wilwood High-Volume Master Cylinders 260-6765 |
| brand | Wilwood Disc Brakes |
| price | 69.63 |
| blurb | Master Cylinder, Aluminum, Natural, .875 in. Bore, Universal, Each |
| title | Wilwood High-Volume Master Cylinders |
| description | Wilwood high-volume master cylinders are the perfect solution for your braking needs. These master cylinders feature high-pressure die-cast bodies with an 8.2oz integral reservoir. Available in several bore sizes and utilize a 1.430 in. piston stroke. |
item_row
| handle | WIL-260-6765 |
|---|---|
| item_ |
136484 |
| brand_ |
232 |
| brand_ |
Wilwood |
| item_ |
https://d32vzsop7y1h3k.cloudfront.net/0f68b317786a99039afeb7716398749a.JPG |
| item_ |
260-6765 |
| item_ |
Wilwood High Volume Aluminum Master Cylinder - 7/8in Bore |
| item_ |
Brake (Other) |
| item_ |
Brake Master Cylinder |
| item_ |
889545067866 |
| item_ |
69.63 |
| item_ |
75.20 |
| t14_ |
1 |
| mfr_ |
50 |
| dim_ |
1.80 |
| dim_ |
10.10 |
| dim_ |
5.80 |
| dim_ |
3.10 |
| shipping_ |
14.52 |
| item_ |
wil260-6765 |
| taxonomy_ |
5367 |
| collection_ |
273461575722 |
| collection_ |
Brake (Other) |
| status | Active |
| item_ |
1 |
| item_ |
Brakes, Rotors & Pads |
| productTaxonomy | 5367 |
Overview
| Brand | Wilwood Disc Brakes |
|---|---|
| Quantity | Sold individually. |
| Part Type | Master Cylinders |
| Bowl Design | Single |
| Product Line | Wilwood High-Volume Master Cylinders |
| Outlet Size 1 | 1/8 in. NPT |
| Remanufactured | No |
| Outlet Quantity | 1 |
| Pushrod Included | Yes |
| Remote Reservoir | No |
| Reservoir Finish | Natural |
| Hardware Included | No |
| Reservoir Included | Yes |
| Reservoir Material | Aluminum |
| Master Cylinder Usage | Brake/Clutch |
| Master Cylinder Finish | Natural |
| Master Cylinder Stroke | 1.430 in. |
| Mounting Hole Quantity | 2 holes |
| Power Brake Compatible | No |
| Master Cylinder Material | Aluminum |
| Master Cylinder Bore Size | 0.875 in. |
| Manufacturer's Part Number | 260-6765 |
| Mounting Brackets Included | No |
| Master Cylinder Cap Included | Yes |
| Mounting Flange Center to Center Distance (in.) | 2.250 in. |
