Wilwood Aluminum Master Cylinders 260-14157-P
Wilwood Aluminum Master Cylinders 260-14157-P
27 in stock
Couldn't load pickup availability
/update?link=products%2Fwil-260-14157-p_xl_6c16313b-5785-415e-a71f-6ff4f608aef2.jpg){kind=link}
Product Description
Wilwood's Tandem Aluminum Master Cylinder for Mustangs comes with the correct pushrod; a 15/16" bore, and is available in 3 finishes; plain, ball burnished, and black e-coat. These master cylinders are designed primarily for manual applications and include the correct pushrod for the factory 64-72 brake pedal. They're designed for mount flanges from 3.22" to 3.40", which match the 64-72 factory manual master cylinder mount, and offer fluid outlet ports on both sides of the bore. The stroke is set at 1.10" with a volume ratio of 2:1 between the primary and secondary chambers. Machined from high-pressure die castings, each master cylinder weighs only 3lbs, a 75% weight savings over most cast iron OE type master cylinders. We also offer a combination proportioning valve kit, which includes brackets and stainless lines specifically for use with this master cylinder, see PN 260-13190, or 220-13189 for retrofit kit
These Wilwood lightweight aluminum master cylinders provide reliable stopping power for drag race cars, late model stock cars, and off-road vehicles. They utilize standard OEM internal components for dependable performance at an affordable price. They are available with or without large-capacity plastic reservoir and dual outlet bores for responsive performance.
Application Summary
Part Type
description
| market_ |
Wilwood''s Tandem Aluminum Master Cylinder for Mustangs comes with the correct pushrod; a 15/16" bore, and is available in 3 finishes; plain, ball burnished, and black e-coat. These master cylinders are designed primarily for manual applications and include the correct pushrod for the factory 64-72 brake pedal. They''re designed for mount flanges from 3.22" to 3.40", which match the 64-72 factory manual master cylinder mount, and offer fluid outlet ports on both sides of the bore. The stroke is set at 1.10" with a volume ratio of 2:1 between the primary and secondary chambers. Machined from high-pressure die castings, each master cylinder weighs only 3lbs, a 75% weight savings over most cast iron OE type master cylinders. We also offer a combination proportioning valve kit, which includes brackets and stainless lines specifically for use with this master cylinder, see PN 260-13190, or 220-13189 for retrofit kit |
|---|---|
| product_ |
M/C,TANDEM,15/16,FORD/MUSTANG MANUAL |
| product_ |
M/C,TANDEM,15/16,FORD/MUSTANG MANUAL W/ROD ASSEMBLY,WILWOOD,BALL BURNISH |
| product_ |
M/C,TANDEM |
s_item
| department | Brake Systems |
|---|---|
| section | Master Cylinders & Boosters |
| name | Wilwood Aluminum Master Cylinders 260-14157-P |
| brand | Wilwood Disc Brakes |
| price | 298.32 |
| blurb | Master Cylinder, Dual Bowl Design, 0.938 in. Bore, Aluminum, Ball Burnished, Reservoir, Ford, Each |
| title | Wilwood Aluminum Master Cylinders |
| description | These Wilwood lightweight aluminum master cylinders provide reliable stopping power for drag race cars, late model stock cars, and off-road vehicles. They utilize standard OEM internal components for dependable performance at an affordable price. They are available with or without large-capacity plastic reservoir and dual outlet bores for responsive performance. |
item_row
| handle | WIL-260-14157-P |
|---|---|
| item_ |
136507 |
| brand_ |
232 |
| brand_ |
Wilwood |
| item_ |
https://d32vzsop7y1h3k.cloudfront.net/b00904518044e0005f5c2863de111494.JPG |
| item_ |
260-14157-P |
| item_ |
Wilwood High Volume Tandem M/C - 15/16in Bore Ball Burnished-W/Pushrod - Early Mustang |
| item_ |
Brake (Other) |
| item_ |
Brake Master Cylinder |
| item_ |
889545076875 |
| item_ |
298.32 |
| item_ |
322.19 |
| t14_ |
0 |
| mfr_ |
22 |
| dim_ |
3.50 |
| dim_ |
18.00 |
| dim_ |
5.00 |
| dim_ |
5.00 |
| shipping_ |
14.52 |
| item_ |
wil260-14157-P |
| taxonomy_ |
5367 |
| collection_ |
273461575722 |
| collection_ |
Brake (Other) |
| status | Active |
| item_ |
1 |
| item_ |
Brakes, Rotors & Pads |
| productTaxonomy | 5367 |
Overview
| Brand | Wilwood Disc Brakes |
|---|---|
| Quantity | Sold individually. |
| Part Type | Master Cylinders |
| Bowl Design | Dual |
| Product Line | Wilwood Aluminum Master Cylinders |
| Remanufactured | No |
| Pushrod Included | Yes |
| Remote Reservoir | No |
| Reservoir Finish | Ball burnished |
| Hardware Included | Yes |
| Reservoir Included | Yes |
| Reservoir Material | Aluminum |
| Master Cylinder Usage | Brake |
| Master Cylinder Finish | Polished |
| Master Cylinder Stroke | 1.100 in. |
| Mounting Hole Quantity | 2 holes |
| Power Brake Compatible | Yes |
| Master Cylinder Material | Aluminum |
| Master Cylinder Bore Size | 0.937 in. |
| Manufacturer's Part Number | 260-14157-P |
| Mounting Brackets Included | Yes |
| Master Cylinder Cap Included | Yes |
| Mounting Flange Center to Center Distance (in.) | 3.200 in. |
