Wilwood GT Series Fixed Mount Rotor Hats 170-6994
Wilwood GT Series Fixed Mount Rotor Hats 170-6994
50 in stock
Couldn't load pickup availability
Product Description
GT Series Big Brake Flared Bell hats are precision machined from premium aluminum alloys for high strength and attention to minimized weight. Hats in this category feature threaded rotor mount holes for use with standard through-hole mount rotors. Threaded hole hats may also be used with T-Nuts or bobbins designed for use with specially machined slotted hole dynamic mount rotors. When used in conjunction with matched Wilwood rotor hardware kits, GT hats provide solid, reliable performance in the most demanding conditions.Flared Bell Hats are generally used with rotor mount bolt circles of 8.38" and larger. Offsets range from 1.88" to 3.00" for rotor diameters 12.19" and up.
Wilwood GT Series fixed mount rotor hats are precision-machined from premium aluminum alloys for high strength and attention to weight. They feature threaded rotor mount holes for use with specially machined, slotted-hole dynamic mount rotors. Wilwood GT Series fixed mount rotor hats are the perfect choice for your Wilwood brake kits.
Application Summary
Part Type
description
| market_ |
GT Series Big Brake Flared Bell hats are precision machined from premium aluminum alloys for high strength and attention to minimized weight. Hats in this category feature threaded rotor mount holes for use with standard through-hole mount rotors. Threaded hole hats may also be used with T-Nuts or bobbins designed for use with specially machined slotted hole dynamic mount rotors. When used in conjunction with matched Wilwood rotor hardware kits, GT hats provide solid, reliable performance in the most demanding conditions.Flared Bell Hats are generally used with rotor mount bolt circles of 8.38" and larger. Offsets range from 1.88" to 3.00" for rotor diameters 12.19" and up. |
|---|---|
| product_ |
HAT,12x8.75 BC,5x4.50/4.75 MT,1.875 OFF |
| product_ |
HAT,12x8.75 BC,5x4.50/4.75 MT,1.875 OFF 3.064 REG |
| product_ |
BRAKE ROTOR HAT |
s_item
| department | Brake Systems |
|---|---|
| section | Disc Brakes |
| name | Wilwood GT Series Fixed Mount Rotor Hats 170-6994 |
| brand | Wilwood Disc Brakes |
| price | 182.42 |
| blurb | Brake Rotor Hat, Fixed Mount, Aluminum, 12 x 8.75 in. Rotor Pattern, 5 x 4.5/4.75 in. Bolt Pattern, 1.88 in. Offset |
| title | Wilwood GT Series Fixed Mount Rotor Hats |
| description | Wilwood GT Series fixed mount rotor hats are precision-machined from premium aluminum alloys for high strength and attention to weight. They feature threaded rotor mount holes for use with specially machined, slotted-hole dynamic mount rotors. Wilwood GT Series fixed mount rotor hats are the perfect choice for your Wilwood brake kits. |
item_row
| handle | WIL-170-6994 |
|---|---|
| item_ |
139877 |
| brand_ |
232 |
| brand_ |
Wilwood |
| item_ |
https://d32vzsop7y1h3k.cloudfront.net/77cd2f6428c26367323592d1155896b1.JPG |
| item_ |
170-6994 |
| item_ |
Wilwood Hat-BB Front 1.88in Offset 5 x 4.50/4.75 - 12 on 8.75in |
| item_ |
Brake Rotors |
| item_ |
Brake Rotors - 2 Piece |
| item_ |
889545042443 |
| item_ |
182.42 |
| item_ |
197.01 |
| t14_ |
0 |
| mfr_ |
50 |
| dim_ |
2.40 |
| dim_ |
10.40 |
| dim_ |
9.50 |
| dim_ |
2.70 |
| shipping_ |
14.53 |
| item_ |
wil170-6994 |
| taxonomy_ |
5367 |
| collection_ |
273461477418 |
| collection_ |
Brake Rotors |
| status | Active |
| item_ |
1 |
| item_ |
Brakes, Rotors & Pads |
| productTaxonomy | 5367 |
Overview
| Brand | Wilwood Disc Brakes |
|---|---|
| Quantity | Sold individually. |
| Part Type | Brake Rotor Hats |
| Product Line | Wilwood GT Series Fixed Mount Rotor Hats |
| Brake Rotor Hat Type | 1/4-20 in. threaded hole |
| Brake Rotor Hat Color | Black |
| Brake Rotor Hat Material | Aluminum |
| Manufacturer's Part Number | 170-6994 |
| Brake Rotor Hat Bolt Circle | 12 x 8.75 in. |
| Brake Rotor Hat Offset (in.) | 1.88 |
| Brake Rotor Hat Face Thickness (in.) | 0.25 |
| Brake Rotor Hat Stud Hole Diameter (in.) | 0.52 |
