Wilwood Forged Narrow Superlite 6R Big Brake Front Brake Kits 140-15155-D
Wilwood Forged Narrow Superlite 6R Big Brake Front Brake Kits 140-15155-D
18 in stock
Couldn't load pickup availability
Product Description
FNSL6R billet Forged six-piston calipers with 13"-14" rotors deliver the ultimate combination for braking power and style in kits engineered for Wilwood's Pro Spindles and offer complete disc brake upgrade solutions for drop spindle applications on American muscle cars and vintage rods. Now with modified hubs for 5 x 4.50" and 5 x 5.00" bolt circle Wheels. Built exclusively for 17" and larger wheels, SL6 kits enhance tire and suspension upgrades on all types of custom show and high performance dual-purpose street and track machines. A full range of options for caliper finishes and rotor designs are guaranteed to catch the eye of the most discriminating enthusiast while providing optimized brake performance for every individual application.
Wilwood forged narrow Superlite 6R Big Brake front brake kits upgrade your late model ride with increased brake capacity and complimentary style. They're application-specific for a simpler installation and offer full compatibility with OE master cylinder output and ABS functions, where used. These front brake kits feature the extremely durable and efficient body design of their forged narrow 6-piston radial mount calipers. You can choose from optional caliper finishes and rotor designs to meet your personal style and braking requirements. Don't just replace—upgrade to generate big stopping power with Wilwood forged narrow Superlite 6R Big Brake front brake kits.
Application Summary
Part Type
description
| market_ |
FNSL6R billet Forged six-piston calipers with 13"-14" rotors deliver the ultimate combination for braking power and style in kits engineered for Wilwood''s Pro Spindles and offer complete disc brake upgrade solutions for drop spindle applications on American muscle cars and vintage rods. Now with modified hubs for 5 x 4.50" and 5 x 5.00" bolt circle Wheels. Built exclusively for 17" and larger wheels, SL6 kits enhance tire and suspension upgrades on all types of custom show and high performance dual-purpose street and track machines. A full range of options for caliper finishes and rotor designs are guaranteed to catch the eye of the most discriminating enthusiast while providing optimized brake performance for every individual application. |
|---|---|
| product_ |
KIT,FRONT,WWE PRO SPINDLE,BIG BRAKE |
| product_ |
KIT,FRONT,WWE PRO SPINDLE,BIG BRAKE 5x5.00 HUB,13.00 ROTOR,SRP |
| product_ |
BRAKE KIT |
s_item
| department | Brake Systems |
|---|---|
| section | Disc Brakes |
| name | Wilwood Forged Narrow Superlite 6R Big Brake Front Brake Kits 140-15155-D |
| brand | Wilwood Disc Brakes |
| price | 2096.86 |
| blurb | KIT, FRONT, WWE PRO SPINDLE, BIG BRAKE |
| title | Wilwood Forged Narrow Superlite 6R Big Brake Front Brake Kits |
| description | Wilwood forged narrow Superlite 6R Big Brake front brake kits upgrade your late model ride with increased brake capacity and complimentary style. They're application-specific for a simpler installation and offer full compatibility with OE master cylinder output and ABS functions, where used. These front brake kits feature the extremely durable and efficient body design of their forged narrow 6-piston radial mount calipers. You can choose from optional caliper finishes and rotor designs to meet your personal style and braking requirements. Don't just replace—upgrade to generate big stopping power with Wilwood forged narrow Superlite 6R Big Brake front brake kits. |
item_row
| handle | WIL-140-15155-D |
|---|---|
| item_ |
137111 |
| brand_ |
232 |
| brand_ |
Wilwood |
| item_ |
https://d32vzsop7y1h3k.cloudfront.net/2538b0562336b2ef30565ea0ff75bf1f.JPG |
| item_ |
140-15155-D |
| item_ |
Wilwood Narrow Superlite 6R Front Hub Kit 12.88in Drilled WWE ProSpindle (5x4.75in 5x5.00in Hub) |
| item_ |
Big Brake Kits |
| item_ |
Big Brake Kits |
| item_ |
889545074895 |
| item_ |
2096.86 |
| item_ |
2348.49 |
| t14_ |
0 |
| mfr_ |
0 |
| dim_ |
61.00 |
| dim_ |
16.00 |
| dim_ |
15.80 |
| dim_ |
15.50 |
| shipping_ |
30.06 |
| item_ |
wil140-15155-D |
| taxonomy_ |
5367 |
| collection_ |
273461379114 |
| collection_ |
Big Brake Kits |
| status | Active |
| item_ |
1 |
| item_ |
Brakes, Rotors & Pads |
| productTaxonomy | 5367 |
Overview
| Brand | Wilwood Disc Brakes |
|---|---|
| Manufacturer's Part Number | 140-15155-D |
| Part Type | Disc Brake Kits |
| Product Line | Wilwood Forged Narrow Superlite 6R Big Brake Front Brake Kits |
| Position | Front |
| Front Rotor Included | Yes |
| Front Rotor Style | Cross-drilled/Slotted surface |
| Front Rotor Construction | Vented |
| Front Rotor Diameter | 12.88 in./327.20mm |
| Front Rotor Thickness (in.) | 1.10 in. |
| Brake Rotor Bolt Pattern (in.) | Dual 5 x 4.50 in./5 x 5.00 in. |
| Brake Rotor Bolt Pattern (mm) | Dual 5 x 114.30mm/5 x 127.00mm |
| Rear Rotor Included | No |
| Front Caliper Included | Yes |
| Front Caliper Piston Quantity | Six |
| Front Caliper Material | Forged billet aluminum |
| Front Caliper Color | Black |
| Rear Caliper Included | No |
| Brake Pads Included | Yes |
| Friction Material Name | BP-10 |
| Parking Brake Provision | No |
| Minimum Recommended Wheel Diameter (in.) | 17 in. |
| Offset (in.) | 0.680 in. |
| Front Spindles Included | No |
| Master Cylinder Included | No |
| Brake Booster Included | No |
| Remanufactured | No |
| Brake Hoses Included | No |
| Quantity | Sold as a kit. |
| Notes | Use with Art Morrison 9999AME GT sport chassis with Wilwood Pro spindle, Roadster Shop Spec Chassis 2016-9999, or Wilwood Pro Spindle (standard height to 2 in. drop). |
