Wilwood Forged Dynalite Rear Parking Brake Kits 140-14400-D
Wilwood Forged Dynalite Rear Parking Brake Kits 140-14400-D
28 in stock
Couldn't load pickup availability
Product Description
Forged Dynapro Low-Profile Pro-Series rear disc brake kits provide a complete solution for popular muscle car rear axles on applications that require a parking brake assembly and extra clearance for 14.00” to 15.00” rim applications. Forged billet Dynapro Low-Profile four-piston calipers 11.00” one-piece hat and rotor assemblies, and high friction pads provide optimized and balanced braking for all types of custom performance street/strip and show machines. The neatly hidden internal shoe system provides a clean installation with superior static holding power for parking. Optional caliper finishes and rotor designs enable the builder to personalize the style and optimize brake performance for every individual application.
Wilwood forged Dynalite rear parking brake kits provide the best solution for many rear axles requiring a parking brake. The forged billet Dynalite 4-piston calipers, one-piece drum/rotors, and high-friction pads provide balanced braking for all types of performance street, strip, and show machines. Their internal shoe parking brake design stays hidden, but has excellent static holding power for parking. Wilwood offers optional caliper finishes and rotor designs to enable the builder to personalize the style and optimize brake performance for every individual application.
Application Summary
Part Type
description
| market_ |
Forged Dynapro Low-Profile Pro-Series rear disc brake kits provide a complete solution for popular muscle car rear axles on applications that require a parking brake assembly and extra clearance for 14.00” to 15.00” rim applications. Forged billet Dynapro Low-Profile four-piston calipers 11.00” one-piece hat and rotor assemblies, and high friction pads provide optimized and balanced braking for all types of custom performance street/strip and show machines. The neatly hidden internal shoe system provides a clean installation with superior static holding power for parking. Optional caliper finishes and rotor designs enable the builder to personalize the style and optimize brake performance for every individual application. |
|---|---|
| product_ |
KIT,REAR,DISC/DRUM,12 BOLT,2.75/2.81 OFF |
| product_ |
KIT,REAR,DISC/DRUM,12 BOLT,2.75/2.81 OFF 1PC 11.00,STAGGERED MT,SRP,BLACK PWD CT |
| product_ |
BRAKE KIT |
s_item
| department | Brake Systems |
|---|---|
| section | Disc Brakes |
| name | Wilwood Forged Dynalite Rear Parking Brake Kits 140-14400-D |
| brand | Wilwood Disc Brakes |
| price | 1103.86 |
| blurb | Disc Brakes, Rear, Dynalite Series, Cross-Drilled, Slotted Rotors, 4-Piston Black Calipers, GM 10/12-Bolt, Kit |
| title | Wilwood Forged Dynalite Rear Parking Brake Kits |
| description | Wilwood forged Dynalite rear parking brake kits provide the best solution for many rear axles requiring a parking brake. The forged billet Dynalite 4-piston calipers, one-piece drum/rotors, and high-friction pads provide balanced braking for all types of performance street, strip, and show machines. Their internal shoe parking brake design stays hidden, but has excellent static holding power for parking. Wilwood offers optional caliper finishes and rotor designs to enable the builder to personalize the style and optimize brake performance for every individual application. |
item_row
| handle | WIL-140-14400-D |
|---|---|
| item_ |
508976 |
| brand_ |
232 |
| brand_ |
Wilwood |
| item_ |
https://d32vzsop7y1h3k.cloudfront.net/eccd2eda41b421b15609a4ba58be30b9.JPG |
| item_ |
140-14400-D |
| item_ |
Wilwood Dynapro 12 Bolt Low-Pro Rear Kit w/ E-Brake 11in Drilled & slotted / 2.75-2.81in off - Black |
| item_ |
Big Brake Kits |
| item_ |
Big Brake Kits |
| item_ |
889545084566 |
| item_ |
1103.86 |
| item_ |
1236.33 |
| t14_ |
0 |
| mfr_ |
0 |
| dim_ |
45.00 |
| dim_ |
17.00 |
| dim_ |
14.00 |
| dim_ |
14.00 |
| shipping_ |
16.82 |
| item_ |
wil140-14400-D |
| taxonomy_ |
5367 |
| collection_ |
273461379114 |
| collection_ |
Big Brake Kits |
| status | Active |
| item_ |
1 |
| item_ |
Brakes, Rotors & Pads |
| productTaxonomy | 5367 |
Overview
| Brand | Wilwood Disc Brakes |
|---|---|
| Position | Rear |
| Quantity | Sold as a kit. |
| Part Type | Disc Brake Kits |
| Offset (in.) | 2.750 in. |
| Product Line | Wilwood Forged Dynalite Rear Parking Brake Kits |
| Rear Rotor Style | Cross-drilled/Slotted surface |
| Rear Caliper Color | Black |
| Parking Brake Style | Internal drum |
| Rear Rotor Diameter | 11.00 in./279.40mm |
| Rear Rotor Included | Yes |
| Brake Hoses Included | No |
| Front Rotor Included | No |
| Rear Caliper Included | Yes |
| Rear Caliper Material | Forged billet aluminum |
| Brake Booster Included | No |
| Front Caliper Included | No |
| Front Spindles Included | No |
| Parking Brake Provision | Yes |
| Rear Rotor Construction | Vented |
| Master Cylinder Included | No |
| Axle Housing Flange Style | 10/12 Bolt Chevrolet (3.072 in. x 2.40 in.) |
| Manufacturer's Part Number | 140-14400-D |
| Rear Rotor Thickness (in.) | 0.81 |
| Rear Caliper Piston Quantity | Four |
| Brake Rotor Bolt Pattern (mm) | Triple 5 x 114.30mm/5 x 120.65mm/5 x 127.00mm |
| Brake Rotor Bolt Pattern (in.) | Triple 5 x 4.50 in./5 x 4.75 in./5 x 5.00 in. |
| Minimum Recommended Wheel Diameter (in.) | 14 in. |
