Wilwood Forged Narrow Superlite 6R Big Brake Rear Disc Brake Kits 140-13866
Wilwood Forged Narrow Superlite 6R Big Brake Rear Disc Brake Kits 140-13866
12 in stock
Couldn't load pickup availability
Tags
Product Description
Forged Narrow Superlite 6R four piston calipers are combined with BP-10 compound pads and 14.25" rotors in this group of big brake kits for Trucks. This group of specialized kits retain full use of the OE parking brake, master cylinder output, and ABS where used. FNSL6R rear kits provide complimentary style and performance with 14.25" and larger front brake upgrades in conjunction with wheel, tire, and suspension upgrades. Optional caliper finishes and rotor designs enable the builder to match style and performance on all applications.
Wilwood forged narrow Superlite 6R Big Brake rear brake kits upgrade your late model ride with increased brake capacity and complimentary style. Superlite kits are application-specific for a simpler installation and offer full compatibility with OE master cylinder output and ABS functions where used. These 6R Big Brake rear brake kits feature the extremely durable and efficient body design of their forged narrow 6-piston radial mount calipers. You can choose from optional caliper finishes and rotor designs to meet your personal style and braking requirements. Don't just replace--upgrade to generate big stopping power with Wilwood forged narrow Superlite 6R Big Brake rear brake kits.
Application Summary
Fitment
Fitment
Part Type
description
| market_ |
Forged Narrow Superlite 6R four piston calipers are combined with BP-10 compound pads and 14.25" rotors in this group of big brake kits for Trucks. This group of specialized kits retain full use of the OE parking brake, master cylinder output, and ABS where used. FNSL6R rear kits provide complimentary style and performance with 14.25" and larger front brake upgrades in conjunction with wheel, tire, and suspension upgrades. Optional caliper finishes and rotor designs enable the builder to match style and performance on all applications. |
|---|---|
| product_ |
KIT,REAR,FORD,F150,2012-UP,FNSL,14.25 |
| product_ |
KIT,REAR,FORD,F150,2012-UP,FNSL,14.25 ROTOR,BLACK |
| product_ |
BRAKE KIT |
s_item
| department | Brake Systems |
|---|---|
| section | Disc Brakes |
| name | Wilwood Forged Narrow Superlite 6R Big Brake Rear Disc Brake Kits 140-13866 |
| brand | Wilwood Disc Brakes |
| price | 2103.8 |
| blurb | Disc Brakes, Forged Narrow Superlite 6R Big, Rear, Power, Slotted Surface Rotors, Black Calipers, Ford, Kit |
| title | Wilwood Forged Narrow Superlite 6R Big Brake Rear Disc Brake Kits |
| description | Wilwood forged narrow Superlite 6R Big Brake rear brake kits upgrade your late model ride with increased brake capacity and complimentary style. Superlite kits are application-specific for a simpler installation and offer full compatibility with OE master cylinder output and ABS functions where used. These 6R Big Brake rear brake kits feature the extremely durable and efficient body design of their forged narrow 6-piston radial mount calipers. You can choose from optional caliper finishes and rotor designs to meet your personal style and braking requirements. Don't just replace--upgrade to generate big stopping power with Wilwood forged narrow Superlite 6R Big Brake rear brake kits. |
item_row
| handle | WIL-140-13866 |
|---|---|
| item_ |
137189 |
| brand_ |
232 |
| brand_ |
Wilwood |
| item_ |
https://d32vzsop7y1h3k.cloudfront.net/b07ce20fa99af1278db37595309b8896.JPG |
| item_ |
140-13866 |
| item_ |
Wilwood Narrow Superlite 4R RearTruck Kit 14.25in 2012-Up Ford F150 (6 lug) |
| item_ |
Big Brake Kits |
| item_ |
Big Brake Kits |
| item_ |
889545071306 |
| item_ |
2103.80 |
| item_ |
2356.26 |
| t14_ |
2 |
| mfr_ |
10 |
| dim_ |
79.10 |
| dim_ |
16.10 |
| dim_ |
15.90 |
| dim_ |
14.90 |
| shipping_ |
33.96 |
| item_ |
wil140-13866 |
| taxonomy_ |
5367 |
| collection_ |
273461379114 |
| collection_ |
Big Brake Kits |
| status | Active |
| item_ |
1 |
| item_ |
Brakes, Rotors & Pads |
| productTaxonomy | 5367 |
Overview
| Brand | Wilwood Disc Brakes |
|---|---|
| Notes | Will not fit vehicles with electric parking brakes. Brake line kit will not fit 2014 and up models with SVT-width track. 6 lug wheel Bolt Circle Only. Will not fit 7 lug vehicles. |
| Position | Rear |
| Quantity | Sold as a kit. |
| Part Type | Disc Brake Kits |
| Offset (in.) | 0.000 in. |
| Product Line | Wilwood Forged Narrow Superlite 6R Big Brake Rear Disc Brake Kits |
| Rear Rotor Style | Slotted surface |
| Rear Caliper Color | Black |
| Disc Brake Kit Type | Power assist |
| Parking Brake Style | Internal drum |
| Rear Rotor Diameter | 14.25 in./361.95mm |
| Rear Rotor Included | Yes |
| Brake Hoses Included | No |
| Front Rotor Included | No |
| Rear Caliper Included | Yes |
| Rear Caliper Material | Forged billet aluminum |
| Brake Booster Included | No |
| Front Caliper Included | No |
| Front Spindles Included | No |
| Parking Brake Provision | Yes |
| Rear Rotor Construction | Vented |
| Master Cylinder Included | No |
| Manufacturer's Part Number | 140-13866 |
| Rear Rotor Thickness (in.) | 1.25 |
| Rear Caliper Piston Quantity | Six |
| Brake Rotor Bolt Pattern (mm) | 6 x 135.00mm |
| Minimum Recommended Wheel Diameter (in.) | 18 in. |
