Wilwood Forged Narrow Superlite 4R Big Brake Rear Parking Brake Kits 140-13666
Wilwood Forged Narrow Superlite 4R Big Brake Rear Parking Brake Kits 140-13666
30 in stock
Couldn't load pickup availability
Product Description
These versions of Forged Narrow Superlite 4R rear disc kits provide the ultimate Big Brake solution for Bronco 76-77 rear axles with Big Ford New Style flange and bearing. (normally: OE 11 inch diameter brakes and 3300 GVW.) Each includes a high efficiency drum style parking brake assembly. FNSL4R four piston calipers, 13" or 14" two-piece rotors, and high performance BP-10 compound pads provide optimized and balanced braking to compliment front big brake upgrades available for Bronco platform. The neatly hidden internal shoe system provides a clean installation with superior static holding power for parking. Optional caliper finishes and rotor designs allow builders to personalize the style and performance for every application.
Wilwood Forged Narrow Superlite 4R Big Brake rear parking brake kits are the perfect addition to front Big Brake upgrades for incredible stopping power. These disc brake kits feature FNSL4R 4-piston oversize forged billet aluminum calipers, 13 or 14 in. 2-piece premium rotors, and high performance BP-10 compound pads. Also included is a high-quality, drum-style parking brake assembly. The neatly hidden internal shoe system provides a clean installation, with superior static holding power for parking. Wilwood Forged Narrow Superlite 4R Big Brake rear parking brake kits provide the extra power to reel in your beast. Order the kit designed for your vehicle application.
Application Summary
Part Type
description
| market_ |
These versions of Forged Narrow Superlite 4R rear disc kits provide the ultimate Big Brake solution for Bronco 76-77 rear axles with Big Ford New Style flange and bearing. (normally: OE 11 inch diameter brakes and 3300 GVW.) Each includes a high efficiency drum style parking brake assembly. FNSL4R four piston calipers, 13" or 14" two-piece rotors, and high performance BP-10 compound pads provide optimized and balanced braking to compliment front big brake upgrades available for Bronco platform. The neatly hidden internal shoe system provides a clean installation with superior static holding power for parking. Optional caliper finishes and rotor designs allow builders to personalize the style and performance for every application. |
|---|---|
| product_ |
KIT,REAR,DISC/DRUM,BIG FORD,NEW STYLE |
| product_ |
KIT,REAR,DISC/DRUM,BIG FORD,NEW STYLE 2.38 OFFSET,FNSL4R,5x5.50 BC,14.00 |
| product_ |
BRAKE KIT |
s_item
| department | Brake Systems |
|---|---|
| section | Disc Brakes |
| name | Wilwood Forged Narrow Superlite 4R Big Brake Rear Parking Brake Kits 140-13666 |
| brand | Wilwood Disc Brakes |
| price | 2190.68 |
| blurb | FNSL4R Rear P-Brk Kit,14.00" |
| title | Wilwood Forged Narrow Superlite 4R Big Brake Rear Parking Brake Kits |
| description | Wilwood Forged Narrow Superlite 4R Big Brake rear parking brake kits are the perfect addition to front Big Brake upgrades for incredible stopping power. These disc brake kits feature FNSL4R 4-piston oversize forged billet aluminum calipers, 13 or 14 in. 2-piece premium rotors, and high performance BP-10 compound pads. Also included is a high-quality, drum-style parking brake assembly. The neatly hidden internal shoe system provides a clean installation, with superior static holding power for parking. Wilwood Forged Narrow Superlite 4R Big Brake rear parking brake kits provide the extra power to reel in your beast. Order the kit designed for your vehicle application. |
item_row
| handle | WIL-140-13666 |
|---|---|
| item_ |
137218 |
| brand_ |
232 |
| brand_ |
Wilwood |
| item_ |
https://d32vzsop7y1h3k.cloudfront.net/5cc28de38daac83250bfa14c37315d5b.JPG |
| item_ |
140-13666 |
| item_ |
Wilwood Narrow Superlite 4R Rear P-Brk Kit 14.00in Big Ford New 2.38in Off Bronco 5 x 5.50 |
| item_ |
Big Brake Kits |
| item_ |
Big Brake Kits |
| item_ |
889545048711 |
| item_ |
2190.68 |
| item_ |
2453.56 |
| t14_ |
0 |
| mfr_ |
35 |
| dim_ |
80.00 |
| dim_ |
16.00 |
| dim_ |
15.80 |
| dim_ |
15.50 |
| shipping_ |
33.96 |
| item_ |
wil140-13666 |
| taxonomy_ |
5367 |
| collection_ |
273461379114 |
| collection_ |
Big Brake Kits |
| status | Active |
| item_ |
1 |
| item_ |
Brakes, Rotors & Pads |
| productTaxonomy | 5367 |
Overview
| Brand | Wilwood Disc Brakes |
|---|---|
| Manufacturer's Part Number | 140-13666 |
| Part Type | Disc Brake Kits |
| Product Line | Wilwood Forged Narrow Superlite 4R Big Brake Rear Parking Brake Kits |
| Position | Rear |
| Front Rotor Included | No |
| Brake Rotor Bolt Pattern (in.) | 5 x 5.50 in. |
| Brake Rotor Bolt Pattern (mm) | 5 x 139.70mm |
| Differential Case Design Type | Ford 9 in. |
| Axle Housing Flange Style | Big Ford New Style Bronco (3.562 in. x 2.00 in. 5-Lug) |
| Rear Rotor Included | Yes |
| Rear Rotor Style | Slotted surface |
| Rear Rotor Construction | Vented |
| Rear Rotor Diameter | 14.00 in./355.60mm |
| Rear Rotor Thickness (in.) | 1.10 |
| Front Caliper Included | No |
| Rear Caliper Included | Yes |
| Rear Caliper Piston Quantity | Four |
| Rear Caliper Material | Forged billet aluminum |
| Rear Caliper Color | Black |
| Brake Pads Included | Yes |
| Friction Material Name | BP-10 |
| Parking Brake Provision | Yes |
| Parking Brake Style | Internal drum |
| Minimum Recommended Wheel Diameter (in.) | 18 in. |
| Offset (in.) | 2.380 in. |
| Front Spindles Included | No |
| Master Cylinder Included | No |
| Brake Booster Included | No |
| Remanufactured | No |
| Brake Hoses Included | No |
| Quantity | Sold as a kit. |
