WILWOOD 140-13202-R
889545019179

Wilwood DynaPro Dust-Boot Pro Series Front Brake Kits 140-13202-R

Wilwood DynaPro Dust-Boot Pro Series Front Brake Kits 140-13202-R

$1,238.69 USD
$1,156.11 USD $1,238.69 USD
Sale Sold out
Shipping calculated at checkout.

50 in stock

Product Description

Wilwood's new limited offset DP-DB Pro-Series Front Hub Kits for GM 1967-1969 F-Body and 1964-1974 A-Body vehicles offer disc brake upgrade solutions for both OEM Disc & Drum spindles. We have completely redesigned our Pro Series line of brake kits using a larger 11" rotor and new forged aluminum hubs with the express purpose of maintaining the factory wheel position. This new kit widens the track with by only +.19" from original drum brake position, and -.31" from the original disc brake assemblies. Based on the venerable forged billet Dynapro Dust Boot caliper, these kits were developed for applications or locations that require or prefer a dust-booted piston. Dust-booted aluminum pistons provide added protection against road or track born dirt and debris on low to intermediate temperature range applications that may also operate in harsh environments. Most vehicle applications require no modifications for installation, and provide plenty of clearance inside popular 15" wheels. FDL Pro-Series kits can be used with either manual or power boost master cylinders. Kits come complete with calipers, rotors, hub assembly, brackets and hardware. Kit installation requires purchase of additional brake lines shown below.

Wilwood DynaPro Big Brake front brake kits allow you to enhance conventional non-ABS spindles on machines providing big brake stopping power. These kits were developed for when dust-booted pistons are appropriate to provide added protection against dirt and debris in low temperature areas and rough environments. A full range of caliper finish and rotor designs provide options to individualize the style and preferences of any enthusiast. Kits come complete with calipers, rotors, hub assembly, brackets and hardware.

Application Summary

Fitment

Buick Apollo 1973–1974 Buick Gran Sport 1965–1967 Buick Skylark 1964–1972 Buick Riviera 1971
Chevrolet Camaro 1967–1969 Chevrolet Chevelle 1967–1972 Chevrolet Chevy II 1964, 1967–1968 Chevrolet El Camino 1967–1972 Chevrolet Monte Carlo 1970–1972 Chevrolet Nova 1969–1974
GMC Sprint 1971–1972
Oldsmobile 442 1967–1971 Oldsmobile Cutlass 1967–1972 Oldsmobile Cutlass Supreme 1971–1972 Oldsmobile Omega 1973–1974 Oldsmobile Vista Cruiser 1967–1972
Pontiac Firebird 1967–1969 Pontiac Grand Prix 1969 Pontiac GTO 1967–1971 Pontiac LeMans 1964–1972 Pontiac Ventura 1971–1974 Pontiac Tempest 1967

Part Type

Overview

Brand Wilwood Disc Brakes
Notes Includes 1/2 in.-20 wheel studs.
Position Front
Quantity Sold as a kit.
Part Type Disc Brake Kits
Offset (in.) 0.180 in.
Product Line Wilwood DynaPro Dust-Boot Pro Series Front Brake Kits
Front Rotor Style Solid surface
Front Caliper Color Red
Rear Rotor Included No
Brake Hoses Included No
Front Rotor Diameter 11.00 in./279.40mm
Front Rotor Included Yes
Rear Caliper Included No
Brake Booster Included No
Front Caliper Included Yes
Front Caliper Material Forged billet aluminum
Front Spindles Included No
Parking Brake Provision No
Front Rotor Construction Vented
Master Cylinder Included No
Manufacturer's Part Number 140-13202-R
Front Rotor Thickness (in.) 0.81 in.
Brake Rotor Bolt Pattern (mm) Dual 5 x 114.30mm/5 x 120.65mm
Front Caliper Piston Quantity Four
Brake Rotor Bolt Pattern (in.) Dual 5 x 4.50 in./5 x 4.75 in.
Minimum Recommended Wheel Diameter (in.) 14 in.
