Wilwood Forged DPHA Front Caliper Kits 140-13029-R

Name: Wilwood Forged DPHA Front Caliper Kits 140-13029-R
Brand: Wilwood
SKU: wil140-13029-R
Price: 551.23 AUD
Availability: InStock

$551.23 AUD

~~$514.49 AUD~~ $551.23 AUD

Sale Sold out

Tax included. Shipping calculated at checkout.

58 in stock

Product variants

Quantity

Product Description

Wilwood's new DynaPro Honda/Acura Caliper (DPHA) for Honda and Acura models originally equipped with 262mm diameter rotors. These calipers bolt directly to the stock mounts on factory spindles, fit over the OE 262mm diameter rotor, accept the OE brake hose, and clear many factory aluminum wheels including the EM1 Si 15" wheel. Designed around Wilwood's proven DynaPro series four piston calipers, the forged billet bodied DPHA caliper delivers high-strength clamping force and positive stopping power. Four stainless steel pistons provide fully balanced pad loading, along with the corrosion resistance and thermal retardant qualities of the stainless alloy that will keep your calipers cooler and running trouble free for many more miles. Calipers work perfectly with the OE master cylinder and ABS functions, and are available with either black or red high-gloss, high-temp, brake fluid resistant sealed powder coat and feature Wilwood's signature logo.

Wilwood forged DPHA front caliper kits are DynaPro packages specifically designed for Honda® and Acura® models originally equipped with 262mm diameter rotors. Packaged with calipers, pads, and hardware, DPHA calipers are available in several high-gloss, high-temperature, and brake fluid-resistant sealed powdercoat colors with the Wilwood signature logo. DynaPro Honda®/Acura® (DPHA) 4-piston calipers have forged billet bodies to deliver high-strength clamping force and positive stopping power. Plus, the stainless steel pistons provide fully balanced pad loading, along with the corrosion resistance and thermal retardant qualities of the stainless alloy that will keep your calipers cooler and running trouble-free for many more miles. Wilwood forged DPHA front caliper kits bolt directly to the stock mounts on factory spindles, fit over the OE 262mm diameter rotor, accept the OE brake hose, and clear many factory aluminum wheels, including the EM1 Si 15 in. wheel. The calipers also work perfectly with the OE master cylinder and ABS functions.

Application Summary

Fitment

Acura Integra 1990–2001 Acura Legend 1986–1987, 1989–1990

Honda Accord 1988–1989 Honda Civic 1990–2015 Honda Prelude 1988–1991 Honda Fit 2007–2013, 2015–2017 Honda Insight 2010–2014

Fitment

Acura Integra 1990–1993, 1997–2001 (GS) Acura Integra 1990–2001 (LS) Acura Integra 1990–1998 (RS) Acura Integra 1992–2001 (GS-R) Acura Integra 1995–1996 (Special Edition) Acura Integra 1997–1998, 2000–2001 (Type R) Acura Legend 1986–1987, 1989–1990 (Base) Acura Legend 1987, 1989–1990 (L, LS)

Honda Accord 1988 (DX, LX) Honda Accord 1988–1989 (LXi) Honda Accord 1989 (SEi) Honda Civic 1990–2012 (EX) Honda Civic 1993–1997, 2001–2012 (DX) Honda Civic 1994–1995, 1999–2000, 2002–2003 (Si) Honda Civic 1994–1996, 2001–2015 (LX) Honda Civic 1996–1997 (CX) Honda Civic 2001–2005 (HX) Honda Civic 2001–2012 (GX) Honda Civic 2003–2008, 2012–2015 (Hybrid) Honda Civic 2004–2005 (Value Package) Honda Civic 2013–2015 (Hybrid-L, HF) Honda Civic 2015 (SE) Honda Civic 2005 (EX Special Edition, LX Special Edition) Honda Prelude 1988–1990 (2.0 S) Honda Prelude 1988–1991 (2.0 Si) Honda Prelude 1988–1989 (2.0 Si 4WS) Honda Prelude 1990–1991 (Si, Si 4WS, Si ALB) Honda Fit 2007–2013 (Base, Sport) Honda Fit 2015–2017 (EX, EX-L, LX) Honda Insight 2010–2014 (EX, LX) Honda Insight 2011–2014 (Base)

Part Type

description

market_description	Wilwood''s new DynaPro Honda/Acura Caliper (DPHA) for Honda and Acura models originally equipped with 262mm diameter rotors. These calipers bolt directly to the stock mounts on factory spindles, fit over the OE 262mm diameter rotor, accept the OE brake hose, and clear many factory aluminum wheels including the EM1 Si 15" wheel. Designed around Wilwood''s proven DynaPro series four piston calipers, the forged billet bodied DPHA caliper delivers high-strength clamping force and positive stopping power. Four stainless steel pistons provide fully balanced pad loading, along with the corrosion resistance and thermal retardant qualities of the stainless alloy that will keep your calipers cooler and running trouble free for many more miles. Calipers work perfectly with the OE master cylinder and ABS functions, and are available with either black or red high-gloss, high-temp, brake fluid resistant sealed powder coat and feature Wilwood''s signature logo.
product_description_invoice	KIT,FRONT,HONDA/ACURA,DPHA,CALIPERS
product_description_long	KIT,FRONT,HONDA/ACURA,DPHA,CALIPERS RED
product_description_short	BRAKE KIT

s_item

department	Brake Systems
section	Disc Brakes
name	Wilwood Forged DPHA Front Caliper Kits 140-13029-R
brand	Wilwood Disc Brakes
price	459.36
blurb	Brake Calipers, DynaPro Low-Profile Lug Mount, Front, Aluminum, Red, 4-piston, for use on Acura®, Honda®, Kit
title	Wilwood Forged DPHA Front Caliper Kits
description	Wilwood forged DPHA front caliper kits are DynaPro packages specifically designed for Honda® and Acura® models originally equipped with 262mm diameter rotors. Packaged with calipers, pads, and hardware, DPHA calipers are available in several high-gloss, high-temperature, and brake fluid-resistant sealed powdercoat colors with the Wilwood signature logo. DynaPro Honda®/Acura® (DPHA) 4-piston calipers have forged billet bodies to deliver high-strength clamping force and positive stopping power. Plus, the stainless steel pistons provide fully balanced pad loading, along with the corrosion resistance and thermal retardant qualities of the stainless alloy that will keep your calipers cooler and running trouble-free for many more miles. Wilwood forged DPHA front caliper kits bolt directly to the stock mounts on factory spindles, fit over the OE 262mm diameter rotor, accept the OE brake hose, and clear many factory aluminum wheels, including the EM1 Si 15 in. wheel. The calipers also work perfectly with the OE master cylinder and ABS functions.

item_row

handle	WIL-140-13029-R
item_id	138653
brand_id	232
brand_name	Wilwood
item_thumbnail	https://d32vzsop7y1h3k.cloudfront.net/3ea9d3e2e3dad0cc62c5b0fe036891b7.JPG
item_mfr_part_number	140-13029-R
item_title	Wilwood DPHA Front Caliper & Pad Kit Red Honda / Acura w/ 262mm OE Rotor
item_category	Big Brake Kits
item_subcategory	Big Brake Kits
item_barcode	889545018677
item_map	459.36
item_rrp	514.49
t14_qty	8
mfr_qty	50
dim_weight	11.60
dim_length	12.20
dim_width	12.10
dim_height	5.10
shipping_avg	14.83
item_part_number	wil140-13029-R
taxonomy_id	5367
collection_id	273461379114
collection_title	Big Brake Kits
status	Active
item_can_purchase	1
item_old_category	Brakes, Rotors & Pads
productTaxonomy	5367

Overview

Brand	Wilwood Disc Brakes
Notes	For use with Honda® and Acura® stock spindles only. Bolts to factory mounts. Clears most stock 15 in. wheels.
Quantity	Sold as a kit.
Part Type	Brake Calipers
Thread Size	M10 x 1.5
Caliper Logo	Wilwood
Product Line	Wilwood Forged DPHA Front Caliper Kits
Bracket Color	Red
Caliper Color	Red
Caliper Series	Dynapro
Remanufactured	No
Bracket Material	Aluminum
Caliper Material	Aluminum
Brackets Included	Yes
Fittings Included	No
Brake Pad Material	Semi-metallic
Brake Pads Included	Yes
Fitting Attachment 1	Female threads
Piston Diameter (in.)	1.620
Rotor Thickness (in.)	0.830 in.
Caliper Piston Quantity	Four
Parking Brake Provision	No
Manufacturer's Part Number	140-13029-R
