Wilwood Forged DPHA Front Caliper and Rotor Kits 140-12996-D
Wilwood Forged DPHA Front Caliper and Rotor Kits 140-12996-D
53 in stock
Couldn't load pickup availability
Tags
Product Description
Wilwood's new DynaPro Honda/Acura Caliper (DPHA) for Honda and Acura models originally equipped with 262mm diameter rotors. These calipers bolt directly to the stock mounts on factory spindles, fit over the OE 262mm diameter rotor, accept the OE brake hose, and clear many factory aluminum wheels including the EM1 Si 15" wheel. Designed around Wilwood's proven DynaPro series four piston calipers, the forged billet bodied DPHA caliper delivers high-strength clamping force and positive stopping power. Four stainless steel pistons provide fully balanced pad loading, along with the corrosion resistance and thermal retardant qualities of the stainless alloy that will keep your calipers cooler and running trouble free for many more miles. Calipers work perfectly with the OE master cylinder and ABS functions, and are available with either black or red high-gloss, high-temp, brake fluid resistant sealed powder coat and feature Wilwood's signature logo.
Wilwood Forged DPHA front caliper and rotor kits are designed around their DynaPro series 4-piston calipers and forged billet bodied rotors for high-strength clamping and solid stopping performance. These calipers work perfectly with the OE master cylinder and ABS functions, bolt up to the stock mounts on factory spindles, accept OE brake hoses, clear many factory aluminum wheels, and fit over 262mm diameter rotors. The low-dusting pads are firmly balanced by four stainless steel pistons, which provide corrosion resistance and thermal retardant qualities.
Application Summary
Fitment
Fitment
Part Type
description
| market_ |
Wilwood''s new DynaPro Honda/Acura Caliper (DPHA) for Honda and Acura models originally equipped with 262mm diameter rotors. These calipers bolt directly to the stock mounts on factory spindles, fit over the OE 262mm diameter rotor, accept the OE brake hose, and clear many factory aluminum wheels including the EM1 Si 15" wheel. Designed around Wilwood''s proven DynaPro series four piston calipers, the forged billet bodied DPHA caliper delivers high-strength clamping force and positive stopping power. Four stainless steel pistons provide fully balanced pad loading, along with the corrosion resistance and thermal retardant qualities of the stainless alloy that will keep your calipers cooler and running trouble free for many more miles. Calipers work perfectly with the OE master cylinder and ABS functions, and are available with either black or red high-gloss, high-temp, brake fluid resistant sealed powder coat and feature Wilwood''s signature logo. |
|---|---|
| product_ |
KIT,FRONT,HONDA/ACURA,DPHA,DRILLED |
| product_ |
BRAKE KIT |
s_item
| department | Brake Systems |
|---|---|
| section | Disc Brakes |
| name | Wilwood Forged DPHA Front Caliper and Rotor Kits 140-12996-D |
| brand | Wilwood Disc Brakes |
| price | 627.86 |
| blurb | Disc Brakes, Front, Forged DPHA, Cross-drilled/Slotted Rotors, Gray Calipers, for use on Acura®, Honda®, Kit |
| title | Wilwood Forged DPHA Front Caliper and Rotor Kits |
| description | Wilwood Forged DPHA front caliper and rotor kits are designed around their DynaPro series 4-piston calipers and forged billet bodied rotors for high-strength clamping and solid stopping performance. These calipers work perfectly with the OE master cylinder and ABS functions, bolt up to the stock mounts on factory spindles, accept OE brake hoses, clear many factory aluminum wheels, and fit over 262mm diameter rotors. The low-dusting pads are firmly balanced by four stainless steel pistons, which provide corrosion resistance and thermal retardant qualities. |
item_row
| handle | WIL-140-12996-D |
|---|---|
| item_ |
137660 |
| brand_ |
232 |
| brand_ |
Wilwood |
| item_ |
https://d32vzsop7y1h3k.cloudfront.net/9a0fd3fba8f3aa2e46d9c5aeba0da473.JPG |
| item_ |
140-12996-D |
| item_ |
Wilwood DPHA Front Caliper & Rotor Kit Drilled Honda / Acura w/ 262mm OE Rotor |
| item_ |
Big Brake Kits |
| item_ |
Big Brake Kits |
| item_ |
889545018462 |
| item_ |
627.86 |
| item_ |
703.21 |
| t14_ |
1 |
| mfr_ |
49 |
| dim_ |
35.70 |
| dim_ |
12.70 |
| dim_ |
12.60 |
| dim_ |
11.80 |
| shipping_ |
15.56 |
| item_ |
wil140-12996-D |
| taxonomy_ |
5367 |
| collection_ |
273461379114 |
| collection_ |
Big Brake Kits |
| status | Active |
| item_ |
1 |
| item_ |
Brakes, Rotors & Pads |
| productTaxonomy | 5367 |
Overview
| Brand | Wilwood Disc Brakes |
|---|---|
| Notes | Included rotors are coated in Black Electro Coat. |
| Position | Front |
| Quantity | Sold as a kit. |
| Part Type | Disc Brake Kits |
| Product Line | Wilwood Forged DPHA Front Caliper and Rotor Kits |
| Front Rotor Style | Cross-drilled/Slotted surface |
| Front Caliper Color | Gray/Silver |
| Rear Rotor Included | No |
| Brake Hoses Included | No |
| Front Rotor Diameter | 10.32 in./262.13mm |
| Front Rotor Included | Yes |
| Rear Caliper Included | No |
| Brake Booster Included | No |
| Front Caliper Included | Yes |
| Front Caliper Material | Forged billet aluminum |
| Front Spindles Included | No |
| Parking Brake Provision | No |
| Front Rotor Construction | Vented |
| Master Cylinder Included | No |
| Manufacturer's Part Number | 140-12996-D |
| Front Rotor Thickness (in.) | 0.83 in. |
| Brake Rotor Bolt Pattern (mm) | 4 x 100.00mm |
| Front Caliper Piston Quantity | Four |
| Minimum Recommended Wheel Diameter (in.) | 15 in. |
