Product Description
Combination hydro-mechanical Parking Brake calipers use hydraulic pressure from the master cylinder for stopping power, and an internal mechanical lock within the caliper for a parking brake. CPB kits are built primarily for front wheel drive vehicles, and select rear wheel drive axles that are not well suited for internal shoe style parking brakes. The calipers are coupled with oversized two-piece rotor assemblies with aluminum hats and high friction BP-10 compound pads. CPB kits provide the correct balanced brake performance and matching style to compliment front big brake upgrade kits.
Wilwood combination parking brake kits provide the correct balanced brake performance, plus matching style to complement front big brake upgrade kits. These packages combine hydro-mechanical parking brake calipers using hydraulic pressure from the master cylinder for stopping power, and an internal mechanical lock within the caliper for a parking brake. Wilwood couples the calipers to 11 in., one-piece rotor assemblies with integral hats and high-friction BP-10 compound pads. These combination parking brake kits are ideal for select rear-wheel drive axles that are not well-suited for internal shoe-style parking brakes.
Application Summary
Fitment
Fitment
Part Type
description
| market_ |
Combination hydro-mechanical Parking Brake calipers use hydraulic pressure from the master cylinder for stopping power, and an internal mechanical lock within the caliper for a parking brake. CPB kits are built primarily for front wheel drive vehicles, and select rear wheel drive axles that are not well suited for internal shoe style parking brakes. The calipers are coupled with oversized two-piece rotor assemblies with aluminum hats and high friction BP-10 compound pads. CPB kits provide the correct balanced brake performance and matching style to compliment front big brake upgrade kits. |
|---|---|
| product_ |
KIT,REAR,FIAT 500,2012-UP,CPB,.81x11.00 |
| product_ |
KIT,REAR,FIAT 500,2012-UP,CPB,.81x11.00 DRILLED,RED,W/LINES |
| product_ |
BRAKE KIT |
s_item
| department | Brake Systems |
|---|---|
| section | Disc Brakes |
| name | Wilwood Combination Parking Brake Kits 140-12768-DR |
| brand | Wilwood Disc Brakes |
| price | 1214.99 |
| blurb | KIT, REAR, FIAT 500, 2012-UP, CPB, .81x11.00 |
| title | Wilwood Combination Parking Brake Kits |
| description | Wilwood combination parking brake kits provide the correct balanced brake performance, plus matching style to complement front big brake upgrade kits. These packages combine hydro-mechanical parking brake calipers using hydraulic pressure from the master cylinder for stopping power, and an internal mechanical lock within the caliper for a parking brake. Wilwood couples the calipers to 11 in., one-piece rotor assemblies with integral hats and high-friction BP-10 compound pads. These combination parking brake kits are ideal for select rear-wheel drive axles that are not well-suited for internal shoe-style parking brakes. |
item_row
| handle | WIL-140-12768-DR |
|---|---|
| item_ |
137033 |
| brand_ |
232 |
| brand_ |
Wilwood |
| item_ |
https://d32vzsop7y1h3k.cloudfront.net/49ae0af597c30accba2d7278dd4ad437.JPG |
| item_ |
140-12768-DR |
| item_ |
Wilwood Combination Parking Brake Rear Kit 11.00in Drilled Red 2012 Fiat 500 w/ Lines |
| item_ |
Brake (Other) |
| item_ |
Brake Calipers - Perf |
| item_ |
889545017472 |
| item_ |
1214.99 |
| item_ |
1360.79 |
| t14_ |
0 |
| mfr_ |
6 |
| dim_ |
37.00 |
| dim_ |
16.00 |
| dim_ |
13.50 |
| dim_ |
13.50 |
| shipping_ |
15.65 |
| item_ |
wil140-12768-DR |
| taxonomy_ |
5367 |
| collection_ |
273461575722 |
| collection_ |
Brake (Other) |
| status | Active |
| item_ |
1 |
| item_ |
Brakes, Rotors & Pads |
| productTaxonomy | 5367 |
Overview
| Brand | Wilwood Disc Brakes |
|---|---|
| Manufacturer's Part Number | 140-12768-DR |
| Part Type | Disc Brake Kits |
| Product Line | Wilwood Combination Parking Brake Kits |
| Position | Rear |
| Front Rotor Included | No |
| Brake Rotor Bolt Pattern (in.) | 4 x 3.86 in. |
| Brake Rotor Bolt Pattern (mm) | 4 x 98.04mm |
| Rear Rotor Included | Yes |
| Rear Rotor Style | Cross-drilled/Slotted surface |
| Rear Rotor Construction | Vented |
| Rear Rotor Diameter | 11.00 in./279.40mm |
| Rear Rotor Thickness (in.) | 0.81 |
| Front Caliper Included | No |
| Rear Caliper Included | Yes |
| Rear Caliper Piston Quantity | One |
| Rear Caliper Material | Forged billet aluminum |
| Rear Caliper Color | Red |
| Brake Pads Included | Yes |
| Friction Material Name | BP-10 |
| Parking Brake Provision | Yes |
| Parking Brake Style | Integral caliper |
| Minimum Recommended Wheel Diameter (in.) | 15 in. |
| Offset (in.) | 0.000 in. |
| Front Spindles Included | No |
| Master Cylinder Included | No |
| Brake Booster Included | No |
| Remanufactured | No |
| Brake Hoses Included | Yes |
| Quantity | Sold as a kit. |
