Wilwood D154 Rear Parking Brake Kits 140-12567-D
Wilwood D154 Rear Parking Brake Kits 140-12567-D
4 in stock
Couldn't load pickup availability
Tags
Product Description
The D154 Pro Series rear disc conversion kit with integral parking brake provides high-tech styling for the street and rugged durability for the toughest off-road conditions. Experience big brake stopping power from 12.19" diameter rotors and two-piston floating mount calipers for ultimate control with big wheel and tire packages. This kit covers the full range of non-ABS Dana 35 rear axles used over a wide range of Jeep models and feature bolt-on installation and full compatibility with the OE master cylinder output. The neatly hidden internal shoe system provides a clean installation with superior static holding power for parking. D154 rear caliper kits offer a complimentary match to vehicles using Wilwood D52 or D154 calipers on OE or aftermarket spindles. Optional caliper finishes and rotor designs enable the builder to personalize the style and optimize brake performance.
Wilwood D154 rear parking brake kits provide high performance stopping power for musclecars with rear axles that require a parking brake! Featuring forged D154 dual-piston calipers, 12.19 in. one-piece drum and rotors, and high-friction pads, these kits nicely complement your D52 or D154 calipers on OE spindles. Their neatly hidden internal shoe system allows for a clean installation and superior static holding power for parking. Optional caliper finishes and rotor designs let you customize the look and performance of your brakes. Wilwood D154 rear parking brake kits offer balanced, optimized braking for all types of custom performance street/strip and show machines!
Application Summary
Fitment
Fitment
Part Type
description
| market_ |
The D154 Pro Series rear disc conversion kit with integral parking brake provides high-tech styling for the street and rugged durability for the toughest off-road conditions. Experience big brake stopping power from 12.19" diameter rotors and two-piston floating mount calipers for ultimate control with big wheel and tire packages. This kit covers the full range of non-ABS Dana 35 rear axles used over a wide range of Jeep models and feature bolt-on installation and full compatibility with the OE master cylinder output. The neatly hidden internal shoe system provides a clean installation with superior static holding power for parking. D154 rear caliper kits offer a complimentary match to vehicles using Wilwood D52 or D154 calipers on OE or aftermarket spindles. Optional caliper finishes and rotor designs enable the builder to personalize the style and optimize brake performance. |
|---|---|
| product_ |
KIT,REAR,DISC/DRUM, JEEP DANA 35,2.56 |
| product_ |
KIT,REAR,DISC/DRUM, JEEP DANA 35,2.56 OFFSET,D154,1PC ROTOR,DRILLED |
| product_ |
BRAKE KIT |
s_item
| department | Brake Systems |
|---|---|
| section | Disc Brakes |
| name | Wilwood D154 Rear Parking Brake Kits 140-12567-D |
| brand | Wilwood Disc Brakes |
| price | 1094.86 |
| blurb | D154, 1 pc Rotor, 2.56 Offset, 5 Lug, Drilled |
| title | Wilwood D154 Rear Parking Brake Kits |
| description | Wilwood D154 rear parking brake kits provide high performance stopping power for musclecars with rear axles that require a parking brake! Featuring forged D154 dual-piston calipers, 12.19 in. one-piece drum and rotors, and high-friction pads, these kits nicely complement your D52 or D154 calipers on OE spindles. Their neatly hidden internal shoe system allows for a clean installation and superior static holding power for parking. Optional caliper finishes and rotor designs let you customize the look and performance of your brakes. Wilwood D154 rear parking brake kits offer balanced, optimized braking for all types of custom performance street/strip and show machines! |
item_row
| handle | WIL-140-12567-D |
|---|---|
| item_ |
136807 |
| brand_ |
232 |
| brand_ |
Wilwood |
| item_ |
https://d32vzsop7y1h3k.cloudfront.net/af0454e8bd70472d5eaf7fc5e0165741.JPG |
| item_ |
140-12567-D |
| item_ |
Wilwood D154 P/S Park Brake Kit Drilled Jeep Dana 35 2.56 Off 5-lug w/ lines |
| item_ |
Big Brake Kits |
| item_ |
Big Brake Kits |
| item_ |
889545016888 |
| item_ |
1094.86 |
| item_ |
1226.25 |
| t14_ |
0 |
| mfr_ |
0 |
| dim_ |
59.00 |
| dim_ |
16.60 |
| dim_ |
13.90 |
| dim_ |
13.90 |
| shipping_ |
29.72 |
| item_ |
wil140-12567-D |
| taxonomy_ |
5367 |
| collection_ |
273461379114 |
| collection_ |
Big Brake Kits |
| status | Active |
| item_ |
1 |
| item_ |
Brakes, Rotors & Pads |
| productTaxonomy | 5367 |
Overview
| Brand | Wilwood Disc Brakes |
|---|---|
| Manufacturer's Part Number | 140-12567-D |
| Part Type | Disc Brake Kits |
| Product Line | Wilwood D154 Rear Parking Brake Kits |
| Position | Rear |
| Front Rotor Included | No |
| Brake Rotor Bolt Pattern (in.) | Triple 5 x 4.50 in./5 x 4.75 in./5 x 5.00 in. |
| Brake Rotor Bolt Pattern (mm) | Triple 5 x 114.30mm/5 x 120.65mm/5 x 127.00mm |
| Differential Case Design Type | Dana 35 |
| Axle Housing Flange Style | Dana 35 (3.188 in. x 1.59 in.) |
| Rear Rotor Included | Yes |
| Rear Rotor Style | Cross-drilled/Slotted surface |
| Rear Rotor Construction | Vented |
| Rear Rotor Diameter | 12.19 in./309.63mm |
| Rear Rotor Thickness (in.) | 0.81 |
| Front Caliper Included | No |
| Rear Caliper Included | Yes |
| Rear Caliper Piston Quantity | Two |
| Rear Caliper Material | Forged billet aluminum |
| Rear Caliper Color | Black |
| Brake Pads Included | Yes |
| Friction Material Name | BP-10 |
| Parking Brake Provision | Yes |
| Parking Brake Style | Internal drum |
| Minimum Recommended Wheel Diameter (in.) | 16 in. |
| Offset (in.) | 2.560 in. |
| Front Spindles Included | No |
| Master Cylinder Included | No |
| Brake Booster Included | No |
| Remanufactured | No |
| Brake Hoses Included | Yes |
| Quantity | Sold as a kit. |
