Wilwood CPB Disc Brake Kits 140-10159-DR
Wilwood CPB Disc Brake Kits 140-10159-DR
Out of stock
Couldn't load pickup availability
/update?link=products%2Fwil-140-10159-dr_xl.jpg){kind=link}
Tags
Product Description
Combination hydro-mechanical Parking Brake calipers use hydraulic pressure from the master cylinder for stopping power, and an internal mechanical lock within the caliper for a parking brake. CPB kits are built primarily for front wheel drive vehicles, and select rear wheel drive axles that are not well suited for internal shoe style parking brakes. The calipers are coupled with oversized two-piece rotor assemblies with aluminum hats and high friction BP-10 compound pads. CPB kits provide the correct balanced brake performance and matching style to compliment front big brake upgrade kits.
These Wilwood CPB disc brake kits use hydraulic pressure from the master cylinder for stopping power and an internal mechanical lock within the caliper for a parking brake. They are built primarily for front-wheel drive and select rear-wheel drive vehicles with axles that are not well suited for internal shoe-style parking brakes. The kits include single-piston brake calipers, coupled with oversized two-piece brake rotor assemblies with aluminum hats and high-friction BP-10 compound brake pads. The Wilwood CPB disc brake kits also provide the correct balanced brake performance and matching style to complement front big brake upgrade kits.
Application Summary
Fitment
Fitment
Part Type
description
| market_ |
Combination hydro-mechanical Parking Brake calipers use hydraulic pressure from the master cylinder for stopping power, and an internal mechanical lock within the caliper for a parking brake. CPB kits are built primarily for front wheel drive vehicles, and select rear wheel drive axles that are not well suited for internal shoe style parking brakes. The calipers are coupled with oversized two-piece rotor assemblies with aluminum hats and high friction BP-10 compound pads. CPB kits provide the correct balanced brake performance and matching style to compliment front big brake upgrade kits. |
|---|---|
| product_ |
KIT,REAR,CPB,MUSTANG 05-UP,1.00 OFFSET |
| product_ |
KIT,REAR,CPB,MUSTANG 05-UP,1.00 OFFSET 12.90 ROTOR,DRLL,RED |
| product_ |
BRAKE KIT |
s_item
| department | Brake Systems |
|---|---|
| section | Disc Brakes |
| name | Wilwood CPB Disc Brake Kits 140-10159-DR |
| brand | Wilwood Disc Brakes |
| price | 1569.93 |
| blurb | Disc Brakes, CPB, Rear, Cross-drilled/Slotted Surface Rotors, Calipers, Aluminum, Red, Ford, 8.8 in., Kit |
| title | Wilwood CPB Disc Brake Kits |
| description | These Wilwood CPB disc brake kits use hydraulic pressure from the master cylinder for stopping power and an internal mechanical lock within the caliper for a parking brake. They are built primarily for front-wheel drive and select rear-wheel drive vehicles with axles that are not well suited for internal shoe-style parking brakes. The kits include single-piston brake calipers, coupled with oversized two-piece brake rotor assemblies with aluminum hats and high-friction BP-10 compound brake pads. The Wilwood CPB disc brake kits also provide the correct balanced brake performance and matching style to complement front big brake upgrade kits. |
item_row
| handle | WIL-140-10159-DR |
|---|---|
| item_ |
138006 |
| brand_ |
232 |
| brand_ |
Wilwood |
| item_ |
https://d32vzsop7y1h3k.cloudfront.net/a069858f5590b3ae5f20aba32d0dff0d.JPG |
| item_ |
140-10159-DR |
| item_ |
Wilwood Combination Parking Brake Rear Kit 12.88in Drilled Red 2005-2014 Mustang |
| item_ |
Brake (Other) |
| item_ |
Brake Calipers - Perf |
| item_ |
889545008579 |
| item_ |
1569.93 |
| item_ |
1758.32 |
| t14_ |
0 |
| mfr_ |
4 |
| dim_ |
49.20 |
| dim_ |
15.90 |
| dim_ |
15.70 |
| dim_ |
15.20 |
| shipping_ |
17.34 |
| item_ |
wil140-10159-DR |
| taxonomy_ |
5367 |
| collection_ |
273461575722 |
| collection_ |
Brake (Other) |
| status | Active |
| item_ |
1 |
| item_ |
Brakes, Rotors & Pads |
| productTaxonomy | 5367 |
Overview
| Brand | Wilwood Disc Brakes |
|---|---|
| Position | Rear |
| Quantity | Sold as a kit. |
| Part Type | Disc Brake Kits |
| Offset (in.) | 2.660 in. |
| Product Line | Wilwood CPB Disc Brake Kits |
| Rear Rotor Style | Cross-drilled/Slotted surface |
| Rear Caliper Color | Red |
| Parking Brake Style | Mechanical caliper |
| Rear Rotor Diameter | 12.88 in./327.15mm |
| Rear Rotor Included | Yes |
| Brake Hoses Included | No |
| Front Rotor Included | No |
| Rear Caliper Included | Yes |
| Rear Caliper Material | Forged billet aluminum |
| Brake Booster Included | No |
| Front Caliper Included | No |
| Front Spindles Included | No |
| Parking Brake Provision | Yes |
| Rear Rotor Construction | Vented |
| Master Cylinder Included | No |
| Axle Housing Flange Style | Ford Mustang 05/14 8.8 in. (2.304 in. x 3.746 in.) |
| Manufacturer's Part Number | 140-10159-DR |
| Rear Rotor Thickness (in.) | 1.00 |
| Rear Caliper Piston Quantity | One |
| Brake Rotor Bolt Pattern (mm) | 5 x 114.30mm |
| Differential Case Design Type | Ford 8.8 in. |
| Brake Rotor Bolt Pattern (in.) | 5 x 4.50 in. |
| Minimum Recommended Wheel Diameter (in.) | 17 in. |
