Wilwood Forged Narrow Superlite 4R Big Brake Rear Parking Brake Kits 140-10093-R
Wilwood Forged Narrow Superlite 4R Big Brake Rear Parking Brake Kits 140-10093-R
Regular price
$2,336.69 USD
Regular price
$2,180.91 USD
Sale price
$2,336.69 USD
Unit price
/
per
Shipping calculated at checkout.
50 in stock
Couldn't load pickup availability
Big Brake Kits
x-v-Wilwood
x-y-1975-1
x-y-1975-2
x-y-1976-1
x-y-1976-2
x-y-1977-1
x-y-1977-2
x-y-1978-1
x-y-1978-2
x-y-1979-1
x-y-1979-2
x-y-1980-1
x-y-1980-2
x-y-1981-1
x-y-1981-2
x-y-1982-1
x-y-1982-2
x-y-1983-1
x-y-1983-2
x-y-1984-1
x-y-1984-2
x-y-1985-1
x-y-1985-2
x-y-1986-1
x-y-1986-2
x-y-1987-1
x-y-1987-2
Big Brake Kits
Tags
L63354961962
Product Description
Forged Narrow Superlite 4R rear disc kits provide the ultimate Big Brake solution for popular muscle car rear axles that require a parking brake. FNSL4R four piston calipers, 13" or 14" two-piece rotors, and high performance BP-10 compound pads provide optimized and balanced braking to compliment front big brake upgrades on all types of custom, show and high performance street machines. The neatly hidden internal shoe system provides a clean installation with superior static holding power for parking. Optional caliper finishes and rotor designs allow builders to personalize the style and performance for every application.
Wilwood Forged Narrow Superlite 4R Big Brake rear parking brake kits are the perfect addition to front Big Brake upgrades for incredible stopping power. These disc brake kits feature FNSL4R 4-piston oversize forged billet aluminum calipers, 13 or 14 in. 2-piece premium rotors, and high performance BP-10 compound pads. Also included is a high-quality, drum-style parking brake assembly. The neatly hidden internal shoe system provides a clean installation, with superior static holding power for parking. Wilwood Forged Narrow Superlite 4R Big Brake rear parking brake kits provide the extra power to reel in your beast. Order the kit designed for your vehicle application.
Application Summary
Fitment
Chevrolet
K5 Blazer
1975–1982
Chevrolet
C10
1975–1986
Chevrolet
C10 Suburban
1975–1986
Chevrolet
R10
1987
Chevrolet
R10 Suburban
1987
GMC
C15
1975–1978
GMC
C1500
1979–1986
GMC
C15 Suburban
1975–1978
GMC
C1500 Suburban
1979–1986
GMC
Jimmy
1975–1984
GMC
P15
1975–1978
GMC
P1500
1979–1980
GMC
R1500
1987
GMC
R1500 Suburban
1987
Fitment
Chevrolet
K5 Blazer
1976
(Base)
Chevrolet
K5 Blazer
1975–1980
(Cheyenne)
Chevrolet
K5 Blazer
1981–1982
(Custom)
Chevrolet
K5 Blazer
1977–1980
(Custom Deluxe)
Chevrolet
K5 Blazer
1981
(Deluxe)
Chevrolet
K5 Blazer
1978, 1980–1982
(Silverado)
Chevrolet
C10
1975–1981
(Cheyenne)
Chevrolet
C10
1981–1986
(Custom)
Chevrolet
C10
1975–1980
(Custom Deluxe)
Chevrolet
C10
1981
(Deluxe)
Chevrolet
C10
1975–1986
(Scottsdale, Silverado)
Chevrolet
C10
1978–1980
(Big Ten)
Chevrolet
C10 Suburban
1981–1986
(Custom)
Chevrolet
C10 Suburban
1975–1980
(Custom Deluxe)
Chevrolet
C10 Suburban
1981
(Deluxe)
Chevrolet
C10 Suburban
1975–1980, 1982, 1984–1986
(Scottsdale)
Chevrolet
C10 Suburban
1975–1980, 1982–1986
(Silverado)
Chevrolet
R10
1987
(Custom Deluxe, Scottsdale, Silverado)
Chevrolet
R10 Suburban
1987
(Custom Deluxe, Scottsdale, Silverado)
GMC
C15
1975–1978
(Base, High Sierra, Sierra Classic, Sierra Grande)
GMC
C15
1977
(Indy Hauler)
GMC
C15
1978
(Street Coupe)
GMC
C15
1977–1978
(Heavy Half)
GMC
C1500
1979–1986
(Base, High Sierra, Sierra Classic)
GMC
C1500
1979–1982
(Sierra Grande, Street Coupe)
GMC
C1500
1979–1980
(Heavy Half)
GMC
C15 Suburban
1975–1978
(Base, High Sierra, Sierra Classic, Sierra Grande)
GMC
C1500 Suburban
1979–1986
(Base, High Sierra, Sierra Classic)
GMC
C1500 Suburban
1979–1982
(Sierra Grande)
GMC
Jimmy
1975–1984
(Base, High Sierra)
GMC
Jimmy
1975–1976, 1978–1984
(Sierra Classic)
GMC
Jimmy
1975–1982
(Sierra Grande)
GMC
Jimmy
1978–1982
(Street Coupe)
GMC
P15
1975–1978
(Base, Value Van)
GMC
P1500
1979–1980
(Base, Value Van)
GMC
R1500
1987
(Base, High Sierra, Sierra Classic)
GMC
R1500 Suburban
1987
(Base, High Sierra, Sierra Classic)
Part Type
description
| market_ |
Forged Narrow Superlite 4R rear disc kits provide the ultimate Big Brake solution for popular muscle car rear axles that require a parking brake. FNSL4R four piston calipers, 13" or 14" two-piece rotors, and high performance BP-10 compound pads provide optimized and balanced braking to compliment front big brake upgrades on all types of custom, show and high performance street machines. The neatly hidden internal shoe system provides a clean installation with superior static holding power for parking. Optional caliper finishes and rotor designs allow builders to personalize the style and performance for every application. |
|---|---|
| product_ |
KIT,REAR,C10 CHEVY 63-87,5 LUG,2.42 OFF |
| product_ |
KIT,REAR,C10 CHEVY 63-87,5 LUG,2.42 OFF FNSL4R,13.00 ROTOR,RED |
| product_ |
BRAKE KIT |
s_item
| department | Brake Systems |
|---|---|
| section | Disc Brakes |
| name | Wilwood Forged Narrow Superlite 4R Big Brake Rear Parking Brake Kits 140-10093-R |
| brand | Wilwood Disc Brakes |
| price | 1822.24 |
| blurb | Disc Brakes, Superlte 4R, Rear, Slotted Surface Rotors, 4-piston Red Calipers, Chevy, GMC, Kit |
| title | Wilwood Forged Narrow Superlite 4R Big Brake Rear Parking Brake Kits |
| description | Wilwood Forged Narrow Superlite 4R Big Brake rear parking brake kits are the perfect addition to front Big Brake upgrades for incredible stopping power. These disc brake kits feature FNSL4R 4-piston oversize forged billet aluminum calipers, 13 or 14 in. 2-piece premium rotors, and high performance BP-10 compound pads. Also included is a high-quality, drum-style parking brake assembly. The neatly hidden internal shoe system provides a clean installation, with superior static holding power for parking. Wilwood Forged Narrow Superlite 4R Big Brake rear parking brake kits provide the extra power to reel in your beast. Order the kit designed for your vehicle application. |
item_row
| handle | WIL-140-10093-R |
|---|---|
| item_ |
138013 |
| brand_ |
232 |
| brand_ |
Wilwood |
| item_ |
https://d32vzsop7y1h3k.cloudfront.net/41d5af28fae3df5dca523ce5b3122cc1.JPG |
| item_ |
140-10093-R |
| item_ |
Wilwood Narrow Superlite 4R Rear P-Brk Kit 12.88in Red Chevy C-10 2.42 Offset 5-lug |
| item_ |
Big Brake Kits |
| item_ |
Big Brake Kits |
| item_ |
889545008418 |
| item_ |
1947.24 |
| item_ |
2180.91 |
| t14_ |
0 |
| mfr_ |
50 |
| dim_ |
79.00 |
| dim_ |
16.00 |
| dim_ |
15.80 |
| dim_ |
15.50 |
| shipping_ |
33.66 |
| item_ |
wil140-10093-R |
| taxonomy_ |
5367 |
| collection_ |
273461379114 |
| collection_ |
Big Brake Kits |
| status | Active |
| item_ |
1 |
| item_ |
Brakes, Rotors & Pads |
| productTaxonomy | 5367 |
Overview
| Brand | Wilwood Disc Brakes |
|---|---|
| Notes | Large GM, Impala/Truck flange (3.396 in. x 2.656 in.). Measures 3.396 in. top and bottom bolts center to center. 2.656 in. top to bottom bolts center to center. 2.940 in. center bore. |
| Position | Rear |
| Quantity | Sold as a kit. |
| Part Type | Disc Brake Kits |
| Offset (in.) | 2.420 in. |
| Product Line | Wilwood Forged Narrow Superlite 4R Big Brake Rear Parking Brake Kits |
| Rear Rotor Style | Slotted surface |
| Rear Caliper Color | Red |
| Parking Brake Style | Internal drum |
| Rear Rotor Diameter | 12.88 in./327.15mm |
| Rear Rotor Included | Yes |
| Brake Hoses Included | No |
| Front Rotor Included | No |
| Rear Caliper Included | Yes |
| Rear Caliper Material | Forged billet aluminum |
| Brake Booster Included | No |
| Front Caliper Included | No |
| Front Spindles Included | No |
| Parking Brake Provision | Yes |
| Rear Rotor Construction | Vented |
| Master Cylinder Included | No |
| Axle Housing Flange Style | Large C10 Flange (3.396 in. x 2.65 in.) |
| Manufacturer's Part Number | 140-10093-R |
| Rear Rotor Thickness (in.) | 1.10 |
| Rear Caliper Piston Quantity | Four |
| Brake Rotor Bolt Pattern (mm) | Dual 5 x 114.30mm/5 x 120.65mm |
| Differential Case Design Type | GM 8.5/8.875 in. (12-bolt), truck |
| Brake Rotor Bolt Pattern (in.) | Dual 5 x 4.50 in./5 x 4.75 in. |
| Minimum Recommended Wheel Diameter (in.) | 17 in. |
