Wilwood D8-6 Brake Calipers 120-11711-BK
Wilwood D8-6 Brake Calipers 120-11711-BK
12 in stock
Couldn't load pickup availability
/update?link=products%2Fwil-120-11711-bk_xl.jpg){kind=link}
Product Description
D8-6 front calipers are a direct bolt-on 6 piston replacement for the OE factory 4 piston front calipers on all 1965-82 Corvettes. Forged billet aluminum bodies, stainless steel pistons, and high temperature seals put an end to the rust, bore pitting, and seal failures that plague the original cast iron caliper design.
Does your Corvette need a brake caliper upgrade? These Wilwood D8-6 brake calipers are direct bolt-on replacements for the OE calipers on all 1965-82 Corvettes. Forged billet aluminum bodies, stainless steel pistons, and high-temperature seals put an end to the rust, bore pitting, and seal failures that plague the OE calipers. Wilwood D8-6 brake calipers provide low-maintenance performance, a significant weight savings, high-temperature reliability, and the added benefit of 6-piston pad clamping power. D8-6 calipers mount in the stock location over stock rotors, use the original-style D8 brake pads, and fit snugly inside most '67 or newer production wheels. Some wheels, including the 1965-66 OE "JK" code steel wheels and a few aftermarket replica alloy wheels, will require a 3/16 in. or wider wheel spacer for clearance. These Wilwood D8-6 brake calipers are sure to give your Corvette outstanding braking capabilities over the OE calipers.
Application Summary
Part Type
description
| market_ |
D8-6 front calipers are a direct bolt-on 6 piston replacement for the OE factory 4 piston front calipers on all 1965-82 Corvettes. Forged billet aluminum bodies, stainless steel pistons, and high temperature seals put an end to the rust, bore pitting, and seal failures that plague the original cast iron caliper design. |
|---|---|
| product_ |
CALIPER,D8-6,1.88/1.38/1.25,1.25 ROTOR |
| product_ |
CALIPER,D8-6,1.88/1.38/1.25,1.25 ROTOR R/H,BLACK |
| product_ |
BRAKE CALIPER |
s_item
| department | Brake Systems |
|---|---|
| section | Disc Brakes |
| name | Wilwood D8-6 Brake Calipers 120-11711-BK |
| brand | Wilwood Disc Brakes |
| price | 410.66 |
| blurb | Brake Caliper, D8-6, Aluminum, Black, 6-Piston, Passenger Side Front, Chevy, Each |
| title | Wilwood D8-6 Brake Calipers |
| description | Does your Corvette need a brake caliper upgrade? These Wilwood D8-6 brake calipers are direct bolt-on replacements for the OE calipers on all 1965-82 Corvettes. Forged billet aluminum bodies, stainless steel pistons, and high-temperature seals put an end to the rust, bore pitting, and seal failures that plague the OE calipers. Wilwood D8-6 brake calipers provide low-maintenance performance, a significant weight savings, high-temperature reliability, and the added benefit of 6-piston pad clamping power. D8-6 calipers mount in the stock location over stock rotors, use the original-style D8 brake pads, and fit snugly inside most '67 or newer production wheels. Some wheels, including the 1965-66 OE "JK" code steel wheels and a few aftermarket replica alloy wheels, will require a 3/16 in. or wider wheel spacer for clearance. These Wilwood D8-6 brake calipers are sure to give your Corvette outstanding braking capabilities over the OE calipers. |
item_row
| handle | WIL-120-11711-BK |
|---|---|
| item_ |
139591 |
| brand_ |
232 |
| brand_ |
Wilwood |
| item_ |
https://d32vzsop7y1h3k.cloudfront.net/e59a6dfccc5a45bd123b365e29ae931c.JPG |
| item_ |
120-11711-BK |
| item_ |
Wilwood Caliper-D8-6 R/H Front Black 1.88/1.38/1.25in Pistons 1.25in Disc |
| item_ |
Brake (Other) |
| item_ |
Brake Calipers - Perf |
| item_ |
889545002119 |
| item_ |
410.66 |
| item_ |
443.51 |
| t14_ |
0 |
| mfr_ |
12 |
| dim_ |
6.30 |
| dim_ |
12.50 |
| dim_ |
7.20 |
| dim_ |
3.60 |
| shipping_ |
14.83 |
| item_ |
wil120-11711-BK |
| taxonomy_ |
5367 |
| collection_ |
273461575722 |
| collection_ |
Brake (Other) |
| status | Active |
| item_ |
1 |
| item_ |
Brakes, Rotors & Pads |
| productTaxonomy | 5367 |
Overview
| Brand | Wilwood Disc Brakes |
|---|---|
| Notes | Direct 6-piston bolt-on replacement for factory 4-piston front calipers. |
| Quantity | Sold individually. |
| Part Type | Brake Calipers |
| Caliper Logo | Wilwood |
| Product Line | Wilwood D8-6 Brake Calipers |
| Caliper Color | Black |
| Caliper Series | D8-6 |
| Remanufactured | No |
| Caliper Material | Aluminum |
| Brackets Included | No |
| Fittings Included | No |
| Brake Pads Included | No |
| Piston Diameter (in.) | 1.880/1.380/1.250 |
| Rotor Thickness (in.) | 1.250 in. |
| Caliper Piston Quantity | Six |
| Parking Brake Provision | No |
| Manufacturer's Part Number | 120-11711-BK |
