CSF Racing Radiators 7001
CSF Racing Radiators 7001
75 in stock
Couldn't load pickup availability
Tags
Product Description
CSF, The Cooling Experts, have been serving the US aftermarket for almost 4 decades. With over 30 million units sold, CSF is your exclusive source for Radiators, Condensers, Intercoolers, Inverter Coolers, Racing Radiators and Pressure Caps.
CSF racing radiators feature the most advanced and efficient radiator cores in the industry. Offered for both vehicle-specific and universal applications, they use innovative tube and fin technologies with industry-leading testing methods to maximize airflow and heat dissipation. Specially engineered tubes in the shape of a "B" are carefully formed and then brazed over the seam. CSF is able to use thinner and lighter aluminum because this design is stronger than normal welded "O" shape tubes. With the inlet in the middle of a seam-brazed tube, the surface area of the tubes is increased approximately 15 percent over regular tubes. With CSF's B-tubes you get dual liquid laminar flow and the efficiency of two smaller tubes vs. one large tube in the same space. High-efficiency, multi-louvered fins are precisely aligned to maximize airflow through each radiator core. Fin specifications are carefully measured and calculated for each application, and tested for maximum heat rejection efficiency in CSF's wind-tunnel lab. CSF offers two all-aluminum end-tank designs to match any style and performance needs. CSF 7000 Series racing radiators have OE-style radial tanks that are flat, rounded, and welded together. Perfect for the customer who likes the sleek and smooth look, and wants to display the intricate welding. CSF deep-drawn end tanks are stamped to the same geometry of OE plastic end tanks. The only high performance manufacture to feature this advanced radiator technology; CSF deep-drawn end tanks feature less welding, and are generally considered the strongest tanks in the industry. Additional features of CSF racing radiators include: * Finished with CSF's Show-Stopper mirror polish process * CAD/CAM designed * Racing-style aluminum drain plug * Brazed in a controlled atmosphere brazing (CAB) furnace—the preferred process for aluminum * ISO 9001/9002 certification * Military-grade (special clad) aluminum used for tubes, fins, and headers * Plates and side brackets meet JIS 3003 specifications * Privately owned factories with full in-house tool rooms * CNC-machined fittings * TIG welded
Extended Description
- BMW 325/ 328/330/Z4
Application Summary
Fitment
Fitment
Part Type
Radiator
Additional Information 2
- Get it all from CSF! With over 3000 models to chose from, CSF's coverage is second to none.When you choose CSF, you are dealing directly with the manufacturer, not a broker or an importer. CSF's factories are ISO certified, and are OE suppliers to many US, German and Asian manufacturers. When you purchase a CSF product, you can be rest assured that it has been manufactured on the same production lines with the same high quality standards as their OE customers. Every single radiator is subject to rigorous testing procedures such as Hydrostatic Testing, Vacuum decaying and life cycle testing, and is designed to always be a "drop-in fit".
description
| aaia_ |
Radiator |
|---|---|
| associated_ |
Get it all from CSF! With over 3000 models to chose from, CSF''s coverage is second to none.When you choose CSF, you are dealing directly with the manufacturer, not a broker or an importer. CSF''s factories are ISO certified, and are OE suppliers to many US, German and Asian manufacturers. When you purchase a CSF product, you can be rest assured that it has been manufactured on the same production lines with the same high quality standards as their OE customers. Every single radiator is subject to rigorous testing procedures such as Hydrostatic Testing, Vacuum decaying and life cycle testing, and is designed to always be a "drop-in fit". |
| market_ |
CSF, The Cooling Experts, have been serving the US aftermarket for almost 4 decades. With over 30 million units sold, CSF is your exclusive source for Radiators, Condensers, Intercoolers, Inverter Coolers, Racing Radiators and Pressure Caps. |
| product_ |
BMW 325/ 328/330/Z4 |
| product_ |
2006 BMW 325, 07-09 BMW 328, 06-10 BMW 330, 09-10 BMW Z4 |
| product_ |
CSF 2006 BMW 325 / 07-09 BMW 328 / 06-10 BMW 330 / 09-10 BMW Z4 Radiator |
s_item
| department | Cooling & Heating |
|---|---|
| section | Radiators |
| name | CSF Racing Radiators 7001 |
| brand | CSF Radiator |
| price | 409 |
| blurb | Radiator, Racing, Aluminum, Polished, BMW, 328, 330, Z4 Each |
| title | CSF Racing Radiators |
| description | CSF racing radiators feature the most advanced and efficient radiator cores in the industry. Offered for both vehicle-specific and universal applications, they use innovative tube and fin technologies with industry-leading testing methods to maximize airflow and heat dissipation. Specially engineered tubes in the shape of a "B" are carefully formed and then brazed over the seam. CSF is able to use thinner and lighter aluminum because this design is stronger than normal welded "O" shape tubes. With the inlet in the middle of a seam-brazed tube, the surface area of the tubes is increased approximately 15 percent over regular tubes. With CSF's B-tubes you get dual liquid laminar flow and the efficiency of two smaller tubes vs. one large tube in the same space. High-efficiency, multi-louvered fins are precisely aligned to maximize airflow through each radiator core. Fin specifications are carefully measured and calculated for each application, and tested for maximum heat rejection efficiency in CSF's wind-tunnel lab. CSF offers two all-aluminum end-tank designs to match any style and performance needs. CSF 7000 Series racing radiators have OE-style radial tanks that are flat, rounded, and welded together. Perfect for the customer who likes the sleek and smooth look, and wants to display the intricate welding. CSF deep-drawn end tanks are stamped to the same geometry of OE plastic end tanks. The only high performance manufacture to feature this advanced radiator technology; CSF deep-drawn end tanks feature less welding, and are generally considered the strongest tanks in the industry. Additional features of CSF racing radiators include: * Finished with CSF's Show-Stopper mirror polish process * CAD/CAM designed * Racing-style aluminum drain plug * Brazed in a controlled atmosphere brazing (CAB) furnace—the preferred process for aluminum * ISO 9001/9002 certification * Military-grade (special clad) aluminum used for tubes, fins, and headers * Plates and side brackets meet JIS 3003 specifications * Privately owned factories with full in-house tool rooms * CNC-machined fittings * TIG welded |
item_row
| handle | CSF-7001 |
|---|---|
| item_ |
212143 |
| brand_ |
280 |
| brand_ |
CSF |
| item_ |
https://d32vzsop7y1h3k.cloudfront.net/b6669f702b522c224cf79698c83c8777.JPG |
| item_ |
7001 |
| item_ |
CSF 2006 BMW 325 / 07-09 BMW 328 / 06-10 BMW 330 / 09-10 BMW Z4 Radiator |
| item_ |
Cooling |
| item_ |
Radiators |
| item_ |
710353070017 |
| item_ |
409.00 |
| item_ |
429.00 |
| t14_ |
0 |
| mfr_ |
0 |
| dim_ |
17.60 |
| dim_ |
30.40 |
| dim_ |
22.90 |
| dim_ |
7.20 |
| shipping_ |
14.52 |
| item_ |
csf7001 |
| taxonomy_ |
|
| collection_ |
|
| collection_ |
|
| status | Active |
| item_ |
1 |
Overview
| Brand | CSF Radiator |
|---|---|
| Quantity | Sold individually. |
| Part Type | Radiators |
| Fan Included | No |
| Product Line | CSF Racing Radiators |
| Inlet Location | Upper driver side |
| Radiator Style | Crossflow |
| Outlet Location | Lower passenger side |
| Radiator Finish | Polished |
| Core Width (in.) | 23.63 in. |
| Core Height (in.) | 18.13 in. |
| Radiator Material | Aluminum |
| Radiator Inlet Size | 1.500 in. |
| Transmission Cooler | No |
| Core Thickness (in.) | 1.25 in. |
| Radiator Outlet Size | 1.500 in. |
| Radiator Cap Included | No |
| Manufacturer's Part Number | 7001 |
| Trans Cooler Adapter Fittings Included | No |
