COMETIC GASKET C5751-040

191070006839

Cometic MLS Head Gaskets C5751-040

Name: Cometic MLS Head Gaskets C5751-040
Brand: Cometic Gasket
SKU: cgsC5751-040
Price: 105.54 AUD
Availability: InStock

$105.54 AUD

~~$97.72 AUD~~ $105.54 AUD

Sale Sold out

Tax included. Shipping calculated at checkout.

12 in stock

Product variants

Quantity

Product Description

COMETIC MLS (Multi-Layer Steel) Head Gaskets provide maximum sealing performance for today's high output engines and require no sealants. MLS gaskets are ideal for both aluminum heads to aluminum blocks and aluminum heads to cast iron blocks. They can withstand the shearing force created by the two materials. MLS gaskets have increased strength because they are comprised of multiple layers of stainless steel; which also creates the ability to rebound and resist corrosion. The outer layers are embossed and coated on both sides with Viton (a flouroelastomer rubber based material that is heat resistant to 250 C/ 482 F). Viton is designed to meet the demands of a variety of harsh sealing environments, load conditions, and surface finishes. The center or shim layer is uncoated stainless steel, which can be varied to accommodate multiple thickness requirements.

Cometic MLS head gaskets are constructed from multiple layers of stainless steel for strength and contain load-controlled embossments that conform load distribution across the sealing area. This creates an exceptional seal by requiring less clamp load—resulting in less bore distortion. The stainless steel outer layers utilize FKM (Viton®) rubber coating, a high-temperature and chemical-resistant polymer. A topcoat of PTFE aids in resistance to fret and increased cold sealing. MLS head gaskets are available for most aftermarket cylinder heads; as with all of Cometic's MLS head gaskets, no sealants or re-torque is required.

Extended Description

GM Gen III/IV Small Block V8 LS Series MLS Head Gasket 4.060" Bore.Comprised of mulitple embossed layers of stainless steel with the outer layers utilizing a viton rubber coating.Compressed operating thickness is .040". Each

Application Summary

Fitment

Chevrolet Avalanche 1500 2002–2006 Chevrolet Camaro 1997–2002, 2010–2015 Chevrolet Corvette 1997–2013 Chevrolet Express 2500 2003–2007 Chevrolet Silverado 1500 1999–2013 Chevrolet Silverado 1500 HD 2001–2003, 2005–2006 Chevrolet Silverado 2500 1999–2004 Chevrolet Silverado 2500 HD 2001–2013 Chevrolet Silverado 3500 2001–2006 Chevrolet Suburban 1500 2000–2013 Chevrolet Suburban 2500 2000–2013 Chevrolet Tahoe 2000–2013 Chevrolet SSR 2003–2006 Chevrolet Express 3500 2005–2007 Chevrolet Trailblazer 2006–2009 Chevrolet Avalanche 2007–2013 Chevrolet Silverado 1500 Classic 2007 Chevrolet Silverado 2500 HD Classic 2007 Chevrolet Silverado 3500 Classic 2007 Chevrolet Silverado 1500 HD Classic 2007 Chevrolet Silverado 3500 HD 2007–2013 Chevrolet Colorado 2009–2012 Chevrolet SS 2014–2017 Chevrolet Trailblazer EXT 2003–2006

GMC Savana 1500 2003–2007 GMC Savana 2500 2003–2007 GMC Sierra 1500 1999–2013 GMC Sierra 1500 HD 2001–2003, 2005–2006 GMC Sierra 2500 1999–2004 GMC Sierra 2500 HD 2001–2013 GMC Sierra 3500 2001–2006 GMC Yukon 2000–2013 GMC Yukon XL 1500 2000–2013 GMC Yukon XL 2500 2000–2013 GMC Savana 3500 2004–2007 GMC Envoy 2005–2009 GMC Sierra 1500 Classic 2007 GMC Sierra 1500 HD Classic 2007 GMC Sierra 2500 HD Classic 2007 GMC Sierra 3500 Classic 2007 GMC Sierra 3500 HD 2007–2013 GMC Canyon 2009–2012 GMC Envoy XUV 2004–2005 GMC Envoy XL 2003–2006

Pontiac Firebird 1997–2002 Pontiac GTO 2004–2006 Pontiac G8 2008–2009

Avanti II 2001–2004

Cadillac CTS 2004–2007 Cadillac Escalade 2005–2006, 2009–2013 Cadillac Escalade ESV 2005–2006 Cadillac Escalade EXT 2005–2006

Hummer H2 2005–2007

Saab 9-7x 2008–2009

Fitment

Chevrolet Avalanche 1500 2002–2005 (Base) Chevrolet Avalanche 1500 2003 (North Face, WBH) Chevrolet Avalanche 1500 2002–2003 (On Road Edition) Chevrolet Avalanche 1500 2002–2006 (Z71) Chevrolet Avalanche 1500 2004–2006 (Z66) Chevrolet Avalanche 1500 2005–2006 (LS, LT) Chevrolet Camaro 1997–2002 (Base, Z28) Chevrolet Camaro 1997 (RS) Chevrolet Camaro 1998–2002 (Z28 SS) Chevrolet Camaro 2010–2015 (SS) Chevrolet Corvette 2003 (50th Anniversary Edition, 50th Anniversary Edition Pace Car) Chevrolet Corvette 1997–2013 (Base) Chevrolet Corvette 1998 (Indianapolis 500 Pace Car) Chevrolet Corvette 2001–2004 (Z06) Chevrolet Corvette 2010–2013 (Grand Sport) Chevrolet Express 2500 2003–2007 (Base) Chevrolet Express 2500 2003–2005 (LS) Chevrolet Silverado 1500 2003–2006 (SS) Chevrolet Silverado 1500 1999–2005 (Base) Chevrolet Silverado 1500 1999–2006, 2008–2013 (LS) Chevrolet Silverado 1500 1999–2013 (LT) Chevrolet Silverado 1500 2002–2004, 2006–2013 (WT) Chevrolet Silverado 1500 2004 (Z71 Off-Road) Chevrolet Silverado 1500 2004–2006, 2009–2013 (Hybrid) Chevrolet Silverado 1500 2007–2013 (LTZ) Chevrolet Silverado 1500 2010–2013 (XFE) Chevrolet Silverado 1500 HD 2001–2003, 2005 (LS) Chevrolet Silverado 1500 HD 2001–2003, 2005–2006 (LT) Chevrolet Silverado 1500 HD 2005 (Base) Chevrolet Silverado 2500 1999–2004 (Base, LS, LT) Chevrolet Silverado 2500 2004 (WT) Chevrolet Silverado 2500 HD 2001–2005 (Base) Chevrolet Silverado 2500 HD 2001–2006 (LS) Chevrolet Silverado 2500 HD 2001–2013 (LT) Chevrolet Silverado 2500 HD 2004, 2006–2013 (WT) Chevrolet Silverado 2500 HD 2007–2013 (LTZ) Chevrolet Silverado 3500 2001–2005 (Base) Chevrolet Silverado 3500 2001–2006 (LS, LT) Chevrolet Silverado 3500 2004, 2006 (WT) Chevrolet Suburban 1500 2000–2001, 2006 (Base) Chevrolet Suburban 1500 2000–2013 (LS, LT) Chevrolet Suburban 1500 2004–2006 (Z71) Chevrolet Suburban 1500 2006–2013 (LTZ) Chevrolet Suburban 2500 2000–2001 (Base) Chevrolet Suburban 2500 2000–2013 (LS, LT) Chevrolet Suburban 2500 2007 (LTZ) Chevrolet Tahoe 2000–2001, 2006 (Base) Chevrolet Tahoe 2000–2013 (LS, LT) Chevrolet Tahoe 2003–2006 (Z71) Chevrolet Tahoe 2007–2013 (LTZ) Chevrolet Tahoe 2008–2013 (Hybrid) Chevrolet SSR 2003–2006 (Base) Chevrolet Express 3500 2005–2007 (Base) Chevrolet Express 3500 2005 (LS) Chevrolet Trailblazer 2006–2007 (LS) Chevrolet Trailblazer 2006–2008 (LT) Chevrolet Trailblazer 2006–2009 (SS) Chevrolet Trailblazer 2008 (Base) Chevrolet Avalanche 2007–2012 (LS, LT, LTZ) Chevrolet Avalanche 2013 (Black Diamond LS, Black Diamond LT, Black Diamond LTZ) Chevrolet Silverado 1500 Classic 2007 (LS, LT, SS, WT, Hybrid) Chevrolet Silverado 2500 HD Classic 2007 (LT, LS, WT) Chevrolet Silverado 3500 Classic 2007 (LS, LT, WT) Chevrolet Silverado 1500 HD Classic 2007 (LT) Chevrolet Silverado 3500 HD 2007–2013 (LT, LTZ, WT) Chevrolet Colorado 2009–2012 (LT) Chevrolet SS 2014–2017 (Base) Chevrolet Trailblazer EXT 2003–2006 (LS, LT) Chevrolet Trailblazer EXT 2003–2004 (North Face)

GMC Savana 1500 2003–2007 (Base) GMC Savana 1500 2003–2005 (SLE) GMC Savana 1500 2006–2007 (LS, LT) GMC Savana 2500 2003–2007 (Base) GMC Savana 2500 2003–2005 (SLE) GMC Sierra 1500 2002–2005 (Base) GMC Sierra 1500 2002 (HT) GMC Sierra 1500 1999–2003, 2006, 2008–2013 (SL) GMC Sierra 1500 1999–2013 (SLE, SLT) GMC Sierra 1500 2002–2013 (WT) GMC Sierra 1500 2005–2006, 2009–2013 (Hybrid) GMC Sierra 1500 2010–2013 (XFE) GMC Sierra 1500 2002–2006 (Denali) GMC Sierra 1500 HD 2001–2003, 2005–2006 (SLE, SLT) GMC Sierra 2500 2002–2004 (Base) GMC Sierra 2500 1999–2002 (SL) GMC Sierra 2500 1999–2004 (SLE, SLT) GMC Sierra 2500 2003–2004 (WT) GMC Sierra 2500 HD 2002–2005 (Base) GMC Sierra 2500 HD 2001–2002, 2006 (SL) GMC Sierra 2500 HD 2001–2013 (SLE, SLT) GMC Sierra 2500 HD 2003–2013 (WT) GMC Sierra 2500 HD 2011–2013 (Denali) GMC Sierra 3500 2002–2005 (Base) GMC Sierra 3500 2001–2002, 2006 (SL) GMC Sierra 3500 2001–2006 (SLE, SLT) GMC Sierra 3500 2004–2006 (WT) GMC Yukon 2000–2013 (SLE, SLT) GMC Yukon 2006 (SL) GMC Yukon 2008–2013 (Hybrid) GMC Yukon 2010–2013 (Denali Hybrid) GMC Yukon 2001–2006 (Denali) GMC Yukon XL 1500 2000–2013 (SLE, SLT) GMC Yukon XL 1500 2006 (SL) GMC Yukon XL 1500 2001–2006 (Denali) GMC Yukon XL 2500 2000–2013 (SLE, SLT) GMC Savana 3500 2004–2007 (Base) GMC Savana 3500 2005 (SLE) GMC Envoy 2005–2009 (Denali) GMC Sierra 1500 Classic 2007 (SL, SLE, SLT, WT, Hybrid, Denali) GMC Sierra 1500 HD Classic 2007 (SLE, SLT) GMC Sierra 2500 HD Classic 2007 (SL, SLT, SLE, WT) GMC Sierra 3500 Classic 2007 (SL, SLE, SLT, WT) GMC Sierra 3500 HD 2007–2013 (SLE, SLT, WT) GMC Sierra 3500 HD 2011–2013 (Denali) GMC Canyon 2009–2012 (SLT) GMC Canyon 2010–2012 (SLE) GMC Envoy XUV 2004–2005 (SLE, SLT) GMC Envoy XL 2003–2005 (SLE, SLT) GMC Envoy XL 2005–2006 (Denali)

Pontiac Firebird 1997–2002 (Formula, Trans Am) Pontiac GTO 2004–2006 (Base) Pontiac G8 2008–2009 (GT) Pontiac G8 2009 (GXP)

Avanti II 2001–2004 (Base)

Cadillac CTS 2004–2007 (V) Cadillac Escalade 2005–2006 (Base) Cadillac Escalade 2009–2013 (Hybrid) Cadillac Escalade 2010–2013 (Hybrid Platinum) Cadillac Escalade ESV 2005–2006 (Base) Cadillac Escalade EXT 2005–2006 (Base)

Hummer H2 2005–2007 (Base)

Saab 9-7x 2008–2009 (Aero)

Part Type

Engine Cylinder Head Gasket

description

aaia_part_type_description	Engine Cylinder Head Gasket
market_description	COMETIC MLS (Multi-Layer Steel) Head Gaskets provide maximum sealing performance for today''s high output engines and require no sealants. MLS gaskets are ideal for both aluminum heads to aluminum blocks and aluminum heads to cast iron blocks. They can withstand the shearing force created by the two materials. MLS gaskets have increased strength because they are comprised of multiple layers of stainless steel; which also creates the ability to rebound and resist corrosion. The outer layers are embossed and coated on both sides with Viton (a flouroelastomer rubber based material that is heat resistant to 250 C/ 482 F). Viton is designed to meet the demands of a variety of harsh sealing environments, load conditions, and surface finishes. The center or shim layer is uncoated stainless steel, which can be varied to accommodate multiple thickness requirements.
product_description_extended	GM Gen III/IV Small Block V8 LS Series MLS Head Gasket 4.060" Bore.Comprised of mulitple embossed layers of stainless steel with the outer layers utilizing a viton rubber coating.Compressed operating thickness is .040". Each
product_description_invoice	GM LS1/2/3/6 Gen-3/4 V8 Head Gasket
product_description_long	.040" MLS Cylinder Head Gasket, 4.060" Gasket Bore. Each
product_description_short	Cylinder Head Gasket

s_item

department	Gaskets & Seals
section	Engine Gaskets & Seals
name	Cometic MLS Head Gaskets C5751-040
brand	Cometic
price	87.95
blurb	Head Gasket, 4.060 in. Bore, .040 in. Compressed Thickness, Chevy, 5.7, 6.0L, 6.2L, Each
title	Cometic MLS Head Gaskets
description	Cometic MLS head gaskets are constructed from multiple layers of stainless steel for strength and contain load-controlled embossments that conform load distribution across the sealing area. This creates an exceptional seal by requiring less clamp load—resulting in less bore distortion. The stainless steel outer layers utilize FKM (Viton®) rubber coating, a high-temperature and chemical-resistant polymer. A topcoat of PTFE aids in resistance to fret and increased cold sealing. MLS head gaskets are available for most aftermarket cylinder heads; as with all of Cometic's MLS head gaskets, no sealants or re-torque is required.

item_row

handle	CGS-C5751-040
item_id	279115
brand_id	14
brand_name	Cometic Gasket
item_thumbnail	https://d5otzd52uv6zz.cloudfront.net/a062795f-9611-4878-8375-cd74bf438197-100.jpg
item_mfr_part_number	C5751-040
item_title	Cometic GM LS1 SB 4.060 inch Bore .040 inch MLS Headgasket
item_category	Engine Components
item_subcategory	Head Gaskets
item_barcode	191070006839
item_map	87.95
item_rrp	97.72
t14_qty	13
mfr_qty
dim_weight	1.00
dim_length	24.00
dim_width	9.80
dim_height	0.25
shipping_avg	14.52
item_part_number	cgsC5751-040
taxonomy_id	5372
collection_id
collection_title
status	Active
item_can_purchase	1
productTaxonomy	5372

Overview

Brand	Cometic
Notes	Designed for LS1, LS2, LS3, and LS6.
Quantity	Sold individually.
Bore (mm)	103.124mm
Lock Wire	No
Part Type	Head Gaskets
Bore (in.)	4.060 in.
Product Line	Cometic MLS Head Gaskets
Gasket Material	Multi-layer stainless steel
Compressed Volume (cc)	8.486cc
Compressed Thickness (in.)	0.040 in.
Manufacturer's Part Number	C5751-040
