Bilstein B8 5100 Series Shocks 24-267014

Name: Bilstein B8 5100 Series Shocks 24-267014
Brand: Bilstein
SKU: bil24-267014
Price: 192.0 AUD
Availability: InStock

$192.00 AUD

~~$223.60 AUD~~ $192.00 AUD

Sale Sold out

Tax included. Shipping calculated at checkout.

60 in stock

Product variants

Quantity

Product Description

Bilstein B8 5100 (Ride Height Adjustable) shock absorbers are designed for trucks and SUV's with a front OE coilover style suspension. Multiple snap-ring grooves in the body allow for different spring seat positions, providing 0-2.75 inches of front lift (depending on application). The monotube shock absorbers feature a 46mm digressive piston a with self-adjusting deflective disc valve setting. Bilstein B8 5100 (Ride Height Adjustable) shock absorbers provide increased wheel travel and improved handling. Utilizing a B8 5100 (Ride Height Adjustable) shock absorber is the easiest way to level out your vehicle.

Bilstein B8 5100 Series shocks feature a monotube design for cooler, more efficient operation and longer life. They have the largest available piston diameter, providing superior handling and performance. The shocks' patented digressive valving instantly reacts to changing surface conditions for maximum comfort and control—on and off the road. These shocks also have split compression and rebound valving tuned for each specific application. Order the model designed for your year/make/model. Additional features: * 2 in. seamless extruded tube * 14mm centerless-ground, case-hardened, chromed, and super-polished rod * 46mm Bilstein digressive piston * Self-adjusting, deflective-disc independent rebound and compression

Extended Description

46mm Monotube Shock Absorber

Application Summary

Buick Rainier 2007-2004, Chevrolet Trailblazer 2009-2002, GMC Envoy 2009-2002, Isuzu Ascender 2008-2003, Oldsmobile Bravada 2004-2002, Saab 9-7x 2009-2005

Fitment

Isuzu Ascender 2003–2008

Chevrolet Trailblazer 2002–2009 Chevrolet Trailblazer EXT 2002–2006

GMC Envoy 2002–2009 GMC Envoy XL 2002–2006

Oldsmobile Bravada 2002–2004

Buick Rainier 2004–2007

Saab 9-7x 2005–2009

Fitment

Isuzu Ascender 2003, 2006 (Base) Isuzu Ascender 2003–2006 (LS) Isuzu Ascender 2003–2005 (Limited) Isuzu Ascender 2004–2005, 2007–2008 (S)

Chevrolet Trailblazer 2002–2007 (LS) Chevrolet Trailblazer 2002–2009 (LT) Chevrolet Trailblazer 2002–2003 (LTZ) Chevrolet Trailblazer 2002–2004 (North Face) Chevrolet Trailblazer 2008 (Base) Chevrolet Trailblazer EXT 2002–2006 (LT) Chevrolet Trailblazer EXT 2002–2004 (North Face) Chevrolet Trailblazer EXT 2003–2006 (LS)

GMC Envoy 2002–2009 (SLE, SLT) GMC Envoy 2005–2009 (Denali) GMC Envoy XL 2002–2006 (SLE, SLT) GMC Envoy XL 2005–2006 (Denali)

Oldsmobile Bravada 2002–2004 (Base)

Buick Rainier 2004–2007 (CXL) Buick Rainier 2004–2005 (CXL Plus)

Saab 9-7x 2005 (Arc, Linear) Saab 9-7x 2006–2009 (4.2i, 5.3i)

Part Type

Shock Absorber

description

aaia_part_type_description	Shock Absorber
application_summary	Buick Rainier 2007-2004, Chevrolet Trailblazer 2009-2002, GMC Envoy 2009-2002, Isuzu Ascender 2008-2003, Oldsmobile Bravada 2004-2002, Saab 9-7x 2009-2005
label_description	B8 5100 (Ride Height Adjustable) - Shock Absorber
market_description	Bilstein B8 5100 (Ride Height Adjustable) shock absorbers are designed for trucks and SUV''s with a front OE coilover style suspension. Multiple snap-ring grooves in the body allow for different spring seat positions, providing 0-2.75 inches of front lift (depending on application). The monotube shock absorbers feature a 46mm digressive piston a with self-adjusting deflective disc valve setting. Bilstein B8 5100 (Ride Height Adjustable) shock absorbers provide increased wheel travel and improved handling. Utilizing a B8 5100 (Ride Height Adjustable) shock absorber is the easiest way to level out your vehicle.
product_description_extended	46mm Monotube Shock Absorber
product_description_invoice	GM Trailblazer 02-09 2/4WD Front B8 5100
product_description_long	B8 5100 (Ride Height Adjustable)-Shock Absorber
product_description_short	Shock

s_item

department	Chassis & Suspension
section	Suspension Components
name	Bilstein B8 5100 Series Shocks 24-267014
brand	Bilstein
price	157
blurb	Shock/Strut, 5100 Series, Monotube, Buick, Chevrolet, GMC, Isuzu, Oldsmobile, Saab, Front, Each
title	Bilstein B8 5100 Series Shocks
description	Bilstein B8 5100 Series shocks feature a monotube design for cooler, more efficient operation and longer life. They have the largest available piston diameter, providing superior handling and performance. The shocks' patented digressive valving instantly reacts to changing surface conditions for maximum comfort and control—on and off the road. These shocks also have split compression and rebound valving tuned for each specific application. Order the model designed for your year/make/model. Additional features: * 2 in. seamless extruded tube * 14mm centerless-ground, case-hardened, chromed, and super-polished rod * 46mm Bilstein digressive piston * Self-adjusting, deflective-disc independent rebound and compression

item_row

handle	BIL-24-267014
item_id	145569
brand_id	126
brand_name	Bilstein
item_thumbnail	https://d32vzsop7y1h3k.cloudfront.net/31aa9d7a789226b25902b3ef87327981.JPG
item_mfr_part_number	24-267014
item_title	Bilstein 5100 Series 02-09 Chevrolet Trailblazer Front 46mm Monotube Shock Absorber (Height Adj)
item_category	Shocks & Structs
item_subcategory	Shocks and Struts
item_barcode	651860804521
item_map	157.00
item_rrp	218.90
t14_qty	24
mfr_qty	42
dim_weight	5.20
dim_length	26.90
dim_width	6.40
dim_height	5.90
shipping_avg	14.52
item_part_number	bil24-267014
taxonomy_id	5383
collection_id	273964662826
collection_title	Shocks & Structs
status	Active
item_can_purchase	1
item_old_category	Suspension
productTaxonomy	5383

Overview

Brand	Bilstein
Quantity	Sold individually.
Part Type	Shocks and Struts
Boot Color	Black
Gas Charged	Yes
Ride Height	Stock/Lifted
Upper Mount	Stud
Product Line	Bilstein B8 5100 Series Shocks
Boot Included	Yes
Internal Design	Monotube
Ride Height Note	Additional ride height information may be available for your vehicle, please refer to the app tab.
Adjustable Valving	No
Body Diameter (in.)	1.811
Extended Length (in.)	16.41
Collapsed Length (in.)	11.26
Lifted Amount Range (in.)	0.00-2.50 in.
Manufacturer's Part Number	24-267014
