Aeromotive Atomic Hex Drive Fuel Pumps 11117
Aeromotive Atomic Hex Drive Fuel Pumps 11117
6 in stock
Couldn't load pickup availability
Product Description
Aeromotive Inc. is a true high performance aftermarket manufacturer specializing in fuel delivery and fuel delivery components. Utilizing aerospace tolerances and procedures, three generations of track experience, and a meticulous approach to engineering, Aeromotive Fuel Systems has become the absolute pinnacle of performance fuel delivery.
Designed to feed serious EFI and carbureted engines gasoline (ethanol or methanol), Aeromotive 12 Series hex drive pumps allow you to run them on your camshaft or off the back of a properly prepared dry-sump oil pump. You could also mount the pumps off the engine or in the back of the vehicle, driven by a heavy-duty cable drive. Aeromotive Atomic hex drive fuel pumps can work in high or low-pressure applications. More product features include: * Flows up to 12 gpm * 5,000-plus hp on gas, up to 2,500 hp with methanol * High-efficiency, gerotor pumping mechanism * Tough Type III hard coat anodized body * CNC-machined from 6061 T6 aircraft aluminum * Hex drive collar with 3-bolt Enderle bolt pattern * Standard male 3/8 in. hex driveshaft * 1.25 in. barb and AN-16 male inlet * ORB-12 female outlet port
Extended Description
- 12 GPM Billet Hex Drive Mechanical Fuel Pump.
Application Summary
Part Type
Additional Information 2
- direct drive provides convenience
- can handle either gas or alcohol
- supports around 5000 HP with gas
- supports around 2500 HP with methanol
description
| associated_ |
direct drive provides convenience; can handle either gas or alcohol; supports around 5000 HP with gas; supports around 2500 HP with methanol |
|---|---|
| market_ |
Aeromotive Inc. is a true high performance aftermarket manufacturer specializing in fuel delivery and fuel delivery components. Utilizing aerospace tolerances and procedures, three generations of track experience, and a meticulous approach to engineering, Aeromotive Fuel Systems has become the absolute pinnacle of performance fuel delivery. |
| product_ |
12 GPM Billet Hex Drive Mechanical Fuel Pump. |
| product_ |
Aeromotive Fuel Pump |
| product_ |
Atomic |
| product_ |
Fuel Pump |
s_item
| department | Air & Fuel Delivery |
|---|---|
| section | Fuel Pumps & Regulators |
| name | Aeromotive Atomic Hex Drive Fuel Pumps 11117 |
| brand | Aeromotive |
| price | 1469.95 |
| blurb | Fuel Pump, Atomic, Hex Drive, Billet Aluminum, Black Anodized, -16 AN/1.25 in. hose barb Inlet, -12 AN Outlet, Universal, Kit |
| title | Aeromotive Atomic Hex Drive Fuel Pumps |
| description | Designed to feed serious EFI and carbureted engines gasoline (ethanol or methanol), Aeromotive 12 Series hex drive pumps allow you to run them on your camshaft or off the back of a properly prepared dry-sump oil pump. You could also mount the pumps off the engine or in the back of the vehicle, driven by a heavy-duty cable drive. Aeromotive Atomic hex drive fuel pumps can work in high or low-pressure applications. More product features include: * Flows up to 12 gpm * 5,000-plus hp on gas, up to 2,500 hp with methanol * High-efficiency, gerotor pumping mechanism * Tough Type III hard coat anodized body * CNC-machined from 6061 T6 aircraft aluminum * Hex drive collar with 3-bolt Enderle bolt pattern * Standard male 3/8 in. hex driveshaft * 1.25 in. barb and AN-16 male inlet * ORB-12 female outlet port |
item_row
| handle | AER-11117 |
|---|---|
| item_ |
4339874 |
| brand_ |
155 |
| brand_ |
Aeromotive |
| item_ |
https://d32vzsop7y1h3k.cloudfront.net/6b607079503f61f634d631c9b852564f.JPG |
| item_ |
11117 |
| item_ |
Aeromotive Atomic Hex Drive Fuel Pump |
| item_ |
Fuel Delivery |
| item_ |
Fuel Pumps |
| item_ |
684980002362 |
| item_ |
1514.95 |
| item_ |
|
| t14_ |
0 |
| mfr_ |
|
| dim_ |
5.00 |
| dim_ |
8.20 |
| dim_ |
7.10 |
| dim_ |
6.40 |
| shipping_ |
14.52 |
| item_ |
aer11117 |
| taxonomy_ |
|
| collection_ |
|
| collection_ |
|
| status | Active |
| item_ |
1 |
Overview
| Brand | Aeromotive |
|---|---|
| Notes | Includes both 1.25 in. hose barb and -16 AN male inlet. |
| Quantity | Sold individually. |
| Flow Rate | 12.0 gpm |
| Part Type | Fuel Pumps |
| Product Line | Aeromotive Atomic Hex Drive Fuel Pumps |
| Fuel Pump Type | Mechanical |
| Inlet Quantity | 1 |
| Gasket Included | No |
| Outlet Quantity | 1 |
| Pulley Included | No |
| Inlet Attachment | Hose barb |
| Outlet Attachment | Female straight cut O-ring |
| Fuel Pressure (psi) | 2-200 psi |
| Fuel Pump Inlet Size | 1 1/4 in. |
| Fuel Pump Outlet Size | -12 AN |
| Sending Unit Included | No |
| Wiring Harness Included | No |
| Mounting Bracket Included | No |
| Manufacturer's Part Number | 11117 |
| Mounting Hardware Included | No |
| Fuel Pressure Regulator Included | No |
